Advantech PCM-5820 9696582075嵌入式单板电脑 PDF资料
Advantech PCM-5820 是研华（Advantech）推出的一款 3.5 英寸硬盘大小的嵌入式单板电脑（SBC），基于 x86 架构，主打紧凑尺寸与无风扇运行。
产品特点（5条）
超紧凑板型，尺寸仅 145 × 102 mm，约 3.5 英寸硬盘大小，适合空间受限的嵌入式应用。
板载低功耗处理器，早期搭载 Cyrix GXM-233，后续升级为 Geode GX1 系列，无需 CPU 风扇即可在 0–60°C 环境下工作。
显示接口丰富，集成 VGA/LCD 控制器，支持 18 位 TFT LCD 及 LVDS 接口，CRT 输出最高 1280×1024。
网络与扩展齐全，板载 10/100Base-T 以太网、音频接口、CompactFlash 插槽、PC/104 扩展接口及两个 USB 1.0 端口。
单电源供电，仅需 +5V 供电，功耗依处理器型号不同约 1.4–3.0 A，简化系统电源设计。
产品应用领域（10条）
数字标牌与多媒体展示终端，驱动等离子、LCD 及 TV-out 大屏。
销售点（POS）终端设备。
信息查询机（Kiosk）。
工业自动化控制中的紧凑型计算平台。
需要无风扇运行的嵌入式场景。
空间受限的 OEM 设备集成。
基于 Windows CE 的多媒体播放设备。
指纹识别等生物识别设备的前端处理单元。
网络终端与瘦客户端应用。
老旧 486 级别嵌入式系统的升级替换方案。
结尾：Advantech PCM-5820 以紧凑尺寸、无风扇设计和齐全的板载接口为核心优势，适用于数字标牌、POS 及空间受限的工业嵌入式场景，是早期 x86 嵌入式平台中集成度较高的单板电脑方案。
Advantech PCM-5820 9696582075嵌入式单板电脑 英文介绍
Advantech PCM-5820 is an embedded single board computer (SBC) with a 3.5-inch hard drive size launched by Advantech. It is based on x86 architecture and features compact size and fanless operation.
Product features (5 items)
Ultra compact board with dimensions of only 145 × 102 mm, approximately 3.5 inches in size of a hard drive, suitable for embedded applications with limited space.
Onboard low-power processor, early equipped with Cyrix GXM-233, later upgraded to Geode GX1 series, can operate in 0-60 ° C environment without CPU fan.
Rich display interfaces, integrated VGA/LCD controller, supporting 18 bit TFT LCD and LVDS interfaces, CRT output up to 1280 × 1024.
The network and expansion are complete, with onboard 10/100Base-T Ethernet, audio interface, CompactFlash slot, PC/104 expansion interface, and two USB 1.0 ports.
Single power supply, only requires+5V power supply, with power consumption ranging from approximately 1.4-3.0A depending on the processor model, simplifying the system power design.
Product application areas (10 items)
Digital signage and multimedia display terminals, driving plasma, LCD, and TV out large screens.
Point of sale (POS) terminal equipment.
Information query machine (Kiosk).
Compact computing platform in industrial automation control.
Embedded scenarios that require fanless operation.
Integration of OEM equipment with limited space.
Multimedia playback device based on Windows CE.
The front-end processing unit of biometric devices such as fingerprint recognition.
Network terminals and thin client applications.
Upgrade and replacement plan for old 486 level embedded systems.
Conclusion: Advantech PCM-5820, with its compact size, fanless design, and complete onboard interfaces as its core advantages, is suitable for digital signage, POS, and space constrained industrial embedded scenarios. It is a highly integrated single board computer solution in early x86 embedded platforms.
Advantech PCM-5820 9696582075嵌入式单板电脑 产品图片
