SR489-P5-HI-A20-E 发电机管理继电器
1.产 品 资 料 介 绍：
中文资料：
SR489-P5-HI-A20-E发电机管理继电器是由GE Multilin为489系列制造的，具有一系列独特的技术特点和功能。
这款继电器特别配备了5 A相CT辅助，为发电机提供强大的电流支持。在控制功率方面，它支持90-300 VDC和70265 VAC(48-62 Hz)的宽范围输入，显示出其出色的适应性和稳定性。模拟输出为4至20 mA，为发电机管理系统提供了精确的数据反馈。
此外，SR489-P5-HI-A20-E发电机管理继电器还具有基本显示功能，方便用户直观地查看继电器的状态。值得注意的是，当继电器通电时，继电器触点可能处于不安全状态，因此，如果低电压可访问应用需要输出继电器触点，客户需要确保适当的绝缘水平，以确保安全操作。
在电气保护方面，这款继电器也有出色的表现。其保险丝电流额定值为2.5 A，保险丝类型为5x20mm HRC SLO-BLO Littelfuse，保险丝型号为215-02.5，这些设计都能有效保护继电器免受电气故障的影响。
型号中的489表示该部件所属的系列，接下来的两位数字P5代表相电流输入，具体为5 A相位CT辅助。而数字HI则代表该继电器具有恶劣环境保护功能，其中的H表示它具有化学环境保型涂层，使其能在各种恶劣环境中稳定运行。
总的来说，SR489-P5-HI-A20-E发电机管理继电器是一款功能强大、稳定可靠的设备，适用于各种需要精确控制和管理发电机运行的应用场景。
英文资料
The SR489-P5-HI-A20-E generator management relay is manufactured by GE Multilin for the 489 series and has a series of unique technical features and functions.
This relay is specially equipped with 5 A phase CT assistance, providing strong current support for the generator. In terms of power control, it supports a wide range of inputs of 90-300 VDC and 70265 VAC (48-62 Hz), demonstrating its excellent adaptability and stability. The analog output is 4 to 20 mA, providing precise data feedback for the generator management system.
In addition, the SR489-P5-HI-A20-E generator management relay also has a basic display function, making it convenient for users to visually view the status of the relay. It is worth noting that when the relay is energized, the relay contacts may be in an unsafe state. Therefore, if low voltage accessible applications require the output of relay contacts, customers need to ensure appropriate insulation levels to ensure safe operation.
In terms of electrical protection, this relay also has excellent performance. The rated current of its fuse is 2.5 A, the fuse type is 5x20mm HRC SLO-BLO Litteluse, and the fuse model is 215-02.5. These designs can effectively protect the relay from electrical faults.
The 489 in the model represents the series to which the component belongs, and the next two digits P5 represent the phase current input, specifically the 5 A phase CT assistance. The digital HI represents that the relay has a harsh environmental protection function, where H represents that it has a chemical environmental protection coating, allowing it to operate stably in various harsh environments.
Overall, the SR489-P5-HI-A20-E generator management relay is a powerful, stable and reliable device suitable for various application scenarios that require precise control and management of generator operation.
2.产 品 展 示
3.产 品 展 示
