GALIL DMC-2153-DC24控制卡 PDF资料
GALIL DMC-2153-DC24 是 Galil DMC-21x3 Econo 系列的一款 5 轴以太网运动控制卡，后缀“-DC24”表示配备 18–36 VDC 输入的 DC-DC 转换器选项。
产品特点（5条）
5轴运动控制，支持步进电机、伺服电机或二者组合。
内置DC-DC转换器，可直接接受18–36 VDC单电源供电。
配备以太网口和RS232串口，支持TCP/IP、UDP协议。
紧凑板级设计，96-pin DIN连接器可直接插接互联模块，省去额外电缆。
支持点位定位、线性/圆弧插补、电子齿轮、电子凸轮等多种运动模式。
产品应用领域（10条）
水射流切割设备的多轴协调控制。
机床行业，如磨床、EDM、激光切割机、冲压机床。
食品加工与包装机械。
航天与天文设备，如天线定位、望远镜控制。
产业制造设备，如绕线机、软管编织机、光纤拉伸机。
龙门式输送与双驱同步控制。
医疗设备运动控制。
半导体制造或检测装置。
纺织与地毯加工中的图案切割。
成本敏感型OEM设备的多轴控制。
结尾：GALIL DMC-2153-DC24 以5轴控制、单电源供电和紧凑板级设计为核心优势，适用于水射流切割、机床、食品加工及航天等多类需要精密多轴协调的运动控制场景。
GALIL DMC-2153-DC24控制卡 英文介绍
GALIL DMC-2153-DC24 is a 5-axis Ethernet motion control card from the Galil DMC-21x3 Econo series, with the suffix "- DC24" indicating the option of a DC-DC converter with 18-36 VDC input.
Product features (5 items)
5-axis motion control, supporting stepper motors, servo motors, or a combination of both.
Built in DC-DC converter, can directly accept 18-36 VDC single power supply.
Equipped with Ethernet port and RS232 serial port, supporting TCP/IP and UDP protocols.
Compact board level design, 96 pin DIN connector can be directly plugged into interconnect modules, eliminating the need for additional cables.
Supports multiple motion modes such as point positioning, linear/circular interpolation, electronic gears, and electronic camshafts.
Product application areas (10 items)
Multi axis coordinated control of water jet cutting equipment.
The machine tool industry, such as grinding machines EDM、 Laser cutting machine, stamping machine tool.
Food processing and packaging machinery.
Aerospace and astronomical equipment, such as antenna positioning and telescope control.
Industrial manufacturing equipment, such as winding machines, hose weaving machines, and fiber optic stretching machines.
Longmen conveyor and dual drive synchronous control.
Medical equipment motion control.
Semiconductor manufacturing or testing equipment.
Pattern cutting in textile and carpet processing.
Multi axis control of cost sensitive OEM equipment.
Conclusion: GALIL DMC-2153-DC24 has the core advantages of 5-axis control, single power supply, and compact board level design, and is suitable for various motion control scenarios that require precise multi axis coordination, such as water jet cutting, machine tools, food processing, and aerospace.
GALIL DMC-2153-DC24控制卡 产品图片
