YOKOGAWA PS-502-01控制器 PDF资料
1.产 品 资 料 介 绍：
YOKOGAWA PS-502-01 是横河电机为工业自动化与安全控制系统设计的电源模块，常用于 CENTUM DCS 或 ProSafe-SLS 等系统，为控制器、I/O 模块等提供稳定可靠的直流供电。
输入电压为 24V DC ±10%，可临时承受 +20% 波动。
提供两路输出：稳压输出 20V DC ±1%，非稳压输出 24V DC。
总输出电流最大 1A，两路负载合计不超过此值。
采用串行稳压方式，满载效率约为 71%。
具备电子限流和短路折返保护（短路时约 0.35A）。
内置 2A 快速熔断器，红色 LED 用于输入状态指示。
支持并联冗余配置，双电源时可实现故障无缝切换。
工作温度范围 -20℃ 至 +70℃，存储温度 -25℃ 至 +85℃。
抗冲击能力 10g（16ms），抗振动 10-55Hz（±0.35mm）。
采用 DIN 41612 48 针接口，单 Euro 卡规格（160×100×30 mm）。
防护等级 IP20，适用于机柜内部安装。
前面板配有 LED 状态指示灯，运行状态一目了然。
兼容 ProSafe-SLS 安全系统及 CENTUM CS/VP 系列 DCS。
符合 EN 50081-2 和 EN 50082-2 电磁兼容标准。
适用于石油、化工、电力、水处理等连续运行的严苛工业环境。
综上所述，YOKOGAWA PS-502-01 电源模块具备 24V 输入、双路输出、冗余支持及宽温工作能力，为横河控制系统提供了稳定可靠的供电保障。
YOKOGAWA PS-502-01 is a power module designed by Yokogawa Electric for industrial automation and safety control systems. It is commonly used in systems such as CENTUM DCS or ProSafe SLS to provide stable and reliable DC power supply for controllers, I/O modules, etc.
The input voltage is 24V DC ± 10%, which can temporarily withstand+20% fluctuations.
Provide two outputs: regulated output 20V DC ± 1%, non regulated output 24V DC.
The maximum total output current is 1A, and the total of the two loads does not exceed this value.
Using serial voltage stabilization method, the full load efficiency is about 71%.
Equipped with electronic current limiting and short-circuit turn back protection (approximately 0.35A in case of short circuit).
Built in 2A fast fuse, red LED for input status indication.
Supporting parallel redundant configuration, seamless fault switching can be achieved when using dual power supplies.
The working temperature range is -20 ℃ to+70 ℃, and the storage temperature is -25 ℃ to+85 ℃.
The impact resistance is 10g (16ms), and the vibration resistance is 10-55Hz (± 0.35mm).
Adopting DIN 41612 48 pin interface, single Euro card specification (160 × 100 × 30 mm).
Protection level IP20, suitable for installation inside cabinets.
The front panel is equipped with LED status indicator lights, making the operating status clear at a glance.
Compatible with ProSafe SLS security system and CENTUM CS/VP series DCS.
Compliant with EN 50081-2 and EN 50082-2 electromagnetic compatibility standards.
Suitable for harsh industrial environments such as petroleum, chemical, power, water treatment, etc. that operate continuously.
In summary, the YOKOGAWA PS-502-01 power module has 24V input, dual output, redundant support, and wide temperature operation capability, providing stable and reliable power supply guarantee for the Yokogawa control system.
