HIMA F60DO801数字输出模块  PDF资料

1.产 品 资 料 介 绍：

HIMA F60DO801 数字输出模块是专为安全仪表系统（SIS）设计的故障安全型输出模块，具备高可靠性和全面的诊断能力，适用于SIL 3级安全应用。

1. 8个独立输出通道，可同时驱动多个现场设备。

2. 单通道最大负载电流2A，可直接驱动电磁阀、继电器等设备。

3. 采用继电器输出类型，触点带强制导向功能，确保故障时可靠断开。

4. 每个输出通道内置双安全继电器串联，实现故障导向安全。

5. 通过TÜV认证，满足SIL 3、Cat.4、PL e等国际安全标准。

6. 支持每通道独立诊断，可检测短路、断路、过温等故障。

7. 采用PWM在线脉冲测试技术，不中断工艺即可检测负载回路健康度。

8. 诊断覆盖率超过99%，有效消除隐性故障风险。

9. 故障发生时，受影响通道自动切换至断电安全状态。

10. 通道与背板之间具备500V AC隔离电压，抗干扰能力强。

11. 面板带LED状态指示灯，可直观显示各通道运行及故障状态。

12. 支持热插拔更换（需冗余配置或停机配合）。

13. 宽温工作范围-40℃至+70℃，适应严苛工业环境。

14. 通过ELOP II工程软件进行配置，系统自动识别模块。

15. 适用于石油化工紧急停车、火气系统、电力机组保护等高风险场景。

综上所述，HIMA F60DO801数字输出模块凭借其SIL 3安全等级、8通道2A驱动能力、全面的在线诊断功能以及故障导向安全设计，为石油、化工、电力等行业提供了高可靠的安全联锁执行解决方案。

HIMA F60DO801数字输出模块 英文介绍

The HIMA F60DO801 digital output module is a fail safe output module designed specifically for Safety Instrumented Systems (SIS), with high reliability and comprehensive diagnostic capabilities, suitable for SIL 3 safety applications.

8 independent output channels, capable of driving multiple field devices simultaneously.

The maximum load current of a single channel is 2A, which can directly drive equipment such as solenoid valves and relays.

Adopting relay output type, with forced guidance function on the contacts to ensure reliable disconnection in case of faults.

Each output channel is equipped with dual safety relays connected in series to achieve fault oriented safety.

Through T Ü V certification, it meets international safety standards such as SIL 3, Cat.4, PL e.

Support independent diagnosis for each channel, capable of detecting faults such as short circuits, open circuits, and overheating.

By using PWM online pulse testing technology, the health of the load circuit can be detected without interrupting the process.

The diagnostic coverage rate exceeds 99%, effectively eliminating hidden fault risks.

When a fault occurs, the affected channel automatically switches to a power-off safety state.

There is a 500V AC isolation voltage between the channel and the backplane, with strong anti-interference ability.

The panel is equipped with LED status indicator lights, which can visually display the operation and fault status of each channel.

Support hot swappable replacement (requires redundant configuration or shutdown coordination).

Wide temperature working range -40 ℃ to+70 ℃, suitable for harsh industrial environments.

Configure through ELOP II engineering software, and the system automatically recognizes the module.

Suitable for high-risk scenarios such as emergency shutdown in petrochemical industry, fire and gas systems, and power unit protection.

In summary, the HIMA F60DO801 digital output module provides a highly reliable safety interlock execution solution for industries such as petroleum, chemical, and power, thanks to its SIL 3 safety level, 8-channel 2A drive capability, comprehensive online diagnostic capabilities, and fault oriented safety design.

HIMA F60DO801数字输出模块  产品展示
