Pioneer Magnetics  PM33211BP-5-1-3-F电源模块 PDF资料

1.产 品 资 料 介 绍：

Pioneer Magnetics PM33211BP-5-1-3-F 电源模块产品特点：

1. 产品类型：工业高压开关电源模块，美国Pioneer Magnetics生产。

2. 输入电压：支持200-240VAC宽电压输入，频率50/60Hz。

3. 输入电流：最大输入电流23A。

4. 输出电压：标称54V DC。

5. 输出电流：最大输出电流55A。

6. 输出功率：额定输出功率高达2976W。

7. 高效率：电源转换效率高，有助于节能降耗。

8. 过压保护：输出电压超过安全阈值时自动切断输出。

9. 过流保护：输出电流超过额定值时触发保护。

10. 过热保护：内置温度传感器，高温时自动降功率或切断输出。

11. 短路保护：输出端短路时快速切断输出，故障排除后自动恢复。

12. 低纹波设计：低纹波、低噪声特性，不干扰敏感控制系统信号。

13. 安装方式：螺栓固定式或机架集成安装。

14. 外壳材质：铝合金或冷轧钢板，散热和电磁屏蔽性能良好。

15. 应用领域：适用于半导体制造、医疗成像、工业自动化等精密设备。

综上所述，Pioneer Magnetics PM33211BP-5-1-3-F 是一款大功率、高可靠性的工业开关电源模块，具备完善的保护功能和低噪声特性，适用于对电源稳定性要求严苛的工业及医疗设备应用场景。

Pioneer Magnetics  PM33211BP-5-1-3-F电源模块 英文介绍

Pioneer Magnetics PM33211BP-5-1-3-F Power Module Product Features:

Product Type: Industrial High Voltage Switching Power Supply Module, produced by Pioneer Magnetics in the United States.

Input voltage: Supports 200-240VAC wide voltage input, frequency 50/60Hz.

Input current: Maximum input current of 23A.

Output voltage: nominal 54V DC.

Output current: Maximum output current of 55A.

Output power: The rated output power is up to 2976W.

High efficiency: The power conversion efficiency is high, which helps to save energy and reduce consumption.

Overvoltage protection: Automatically cuts off the output when the output voltage exceeds the safe threshold.

Overcurrent protection: The protection is triggered when the output current exceeds the rated value.

Overheating protection: Built in temperature sensor, automatically reduces power or cuts off output when high temperature occurs.

Short circuit protection: Quickly cut off the output when there is a short circuit at the output end, and automatically restore after troubleshooting.

Low ripple design: With low ripple and low noise characteristics, it does not interfere with sensitive control system signals.

Installation method: bolt fixed or rack integrated installation.

Shell material: aluminum alloy or cold-rolled steel plate, with good heat dissipation and electromagnetic shielding performance.

Application areas: Suitable for precision equipment such as semiconductor manufacturing, medical imaging, and industrial automation.

In summary, Pioneer Magnetics PM33211BP-5-1-3-F is a high-power, high reliability industrial switching power module with complete protection functions and low noise characteristics, suitable for industrial and medical equipment application scenarios that require strict power stability.

Pioneer Magnetics  PM33211BP-5-1-3-F电源模块 产品展示
