ALLEN BRADLEY 1771-OBN输出模块 PDF资料
1.产 品 资 料 介 绍：
Allen-Bradley 1771-OBN 输出模块是 PLC-5 系列的数字量直流输出模块，具备以下 15 条特点：
属于 Allen-Bradley PLC-5 系列 I/O 模块。
提供 32 个数字量输出通道。
输出电压范围为直流 10-30V。
每路输出电流 0.5 安培。
输出类型为直流源型（sourcing）。
背板电流消耗较低。
采用光电隔离技术，抗干扰能力强。
响应速度快，满足快速控制需求。
前面板配备 LED 指示灯，监测各通道状态。
支持机架式安装，适配 1771 I/O 机架。
工作温度范围宽，适应工业环境。
湿度适应范围 5% 至 95%（无冷凝）。
防护等级 IP20，适合柜内安装。
每组输出配备保险丝，提供过流保护。
兼容 PLC-5 系列控制器及 1771 I/O 架构。
结尾：
总之，1771-OBN 模块凭借 32 点高密度输出、光电隔离及可靠驱动能力，适用于制造业、能源管理等需要控制直流负载的工业自动化场景。
ALLEN BRADLEY 1771-OBN输出模块 英文介绍
The Allen Bradley 1771-OBN output module is a digital DC output module of the PLC-5 series, which has the following 15 characteristics:
Belongs to the Allen Bradley PLC-5 series I/O modules.
Provide 32 digital output channels.
The output voltage range is 10-30V DC.
Each output current is 0.5 amperes.
The output type is DC source type (sourcing).
The backplane current consumption is relatively low.
Adopting optoelectronic isolation technology, it has strong anti-interference ability.
Fast response speed, meeting the requirements of quick control.
The front panel is equipped with LED indicator lights to monitor the status of each channel.
Supports rack mounted installation and is compatible with 1771 I/O racks.
Wide working temperature range, suitable for industrial environments.
The humidity adaptation range is 5% to 95% (without condensation).
Protection level IP20, suitable for installation inside cabinets.
Each output is equipped with fuses to provide overcurrent protection.
Compatible with PLC-5 series controllers and 1771 I/O architecture.
ending:
In summary, the 1771-OBN module, with its 32 point high-density output, optoelectronic isolation, and reliable driving capability, is suitable for industrial automation scenarios such as manufacturing and energy management that require control of DC loads.
ALLEN BRADLEY 1771-OBN输出模块 产品展示
