Valmet Metso A413222输出模块电路板 PDF资料
1.产 品 资 料 介 绍：
Valmet Metso A413222 输出模块电路板是 Valmet DNA 系统中的 I/O 接口组件，具备以下 15 条特点：
承担现场信号与控制器之间的转换处理功能。
支持多种热电偶和 RTD 温度传感器输入。
无需外部信号调理器，简化布线。
每通道与背板电气隔离，抗干扰能力强。
测量精度高，分辨率可达 0.01℃。
内置冷端补偿和引线电阻自动补偿。
支持断线检测、超量程报警和漂移监测。
可配置软件滤波，抑制工频干扰。
PCB 采用保形涂层，适应潮湿腐蚀环境。
工作温度范围宽，适应严苛工业现场。
支持热插拔，便于维护更换。
配备可拆卸接线端子，方便接线。
防护等级 IP20，适合柜内安装。
另有 IP65 现场安装版本可选。
兼容 Valmet DNA 及旧版 Damatic XD 系统。
结尾：
总之，该模块适用于造纸、电力、化工、油气等行业对温度监控要求严格的自动化场景。
Valmet Metso A413222输出模块电路板 英文介绍
The Valmet Metso A413222 output module circuit board is an I/O interface component in the Valmet DNA system, with the following 15 characteristics:
Undertake the conversion processing function between on-site signals and controllers.
Supports multiple thermocouple and RTD temperature sensor inputs.
No need for external signal conditionrs, simplifying wiring.
Each channel is electrically isolated from the backplane, with strong anti-interference ability.
High measurement accuracy, with a resolution of up to 0.01 ℃.
Built in cold end compensation and automatic compensation for lead resistance.
Support wire breakage detection, over range alarm, and drift monitoring.
Configurable software filtering to suppress power frequency interference.
PCB adopts conformal coating to adapt to humid and corrosive environments.
Wide working temperature range, suitable for harsh industrial sites.
Supports hot swapping for easy maintenance and replacement.
Equipped with detachable terminal blocks for easy wiring.
Protection level IP20, suitable for installation inside cabinets.
There is also an optional IP65 on-site installation version available.
Compatible with Valmet DNA and older Damatic XD systems.
ending:
In summary, this module is suitable for automation scenarios with strict temperature monitoring requirements in industries such as papermaking, power, chemical, and oil and gas.
Valmet Metso A413222输出模块电路板 产品展示
