Metso A413110印刷电路板 PDF资料
1.产 品 资 料 介 绍：
METSO A413110 是美卓（Metso，现维美德/耐莱斯）A4131系列的一款8通道通用模拟量输入模块，主要用于工业现场的温度、压力、流量等信号的采集与转换。
中间15个特点
METSO A413110 提供8路差分模拟量输入通道，支持多点信号采集。
该模块支持电流（4-20mA、0-20mA）、电压（0-10V、±10V）信号输入。
同时支持PT100、PT1000等热电阻信号和J、K、T、E、R、S、B等多种热电偶信号。
每路通道可独立配置信号类型，无需外部信号调理器。
METSO A413110 采用16位A/D转换，测量精度达±0.1%。
具备1500V AC通道至背板隔离和500V DC通道间隔离，抗干扰能力强。
内置断线检测和超量程诊断功能，每通道配有LED状态指示灯。
工作温度范围为-20℃至+60℃，存储温度为-40℃至+85℃。
防护等级IP20（机架版），另有IP65现场安装版本可选。
支持热插拔，可在背板通电状态下更换模块。
METSO A413110 采用35mm DIN导轨安装，结构紧凑。
与美卓Damatic XD和维美德DNA分布式控制系统深度匹配，即插即用。
采样率10Hz至100Hz可调，适应不同响应速度需求。
采用保形涂层PCB，防潮、防腐蚀，适应恶劣环境。
适用于造纸、电力、化工、采矿、水处理等行业。
结尾
METSO A413110 凭借8通道通用输入、16位高精度采集和宽温设计，成为美卓DCS系统中可靠的模拟量信号采集模块选择。
Metso A413110印刷电路板 英文介绍
METSO A413110 is an 8-channel universal analog input module of the Metso A4131 series, mainly used for the acquisition and conversion of temperature, pressure, flow and other signals in industrial sites.
15 characteristics in the middle
METSO A413110 provides 8 differential analog input channels and supports multi-point signal acquisition.
This module supports current (4-20mA, 0-20mA) and voltage (0-10V, ± 10V) signal inputs.
Simultaneously supporting thermal resistance signals such as PT100 and PT1000, as well as multiple thermocouple signals such as J, K, T, E, R, S, and B.
Each channel can independently configure signal types without the need for external signal conditioners.
METSO A413110 adopts 16 bit A/D conversion, with a measurement accuracy of ± 0.1%.
Equipped with 1500V AC channel to backplane isolation and 500V DC channel isolation, with strong anti-interference ability.
Built in wire breakage detection and over range diagnosis functions, each channel is equipped with LED status indicator lights.
The working temperature range is -20 ℃ to+60 ℃, and the storage temperature is -40 ℃ to+85 ℃.
Protection level IP20 (rack version), with an optional IP65 on-site installation version.
Supports hot swapping and allows for module replacement while the backplane is powered on.
METSO A413110 is installed on a 35mm DIN rail and has a compact structure.
Deeply matched with Meizuo Damatic XD and Valmet DNA distributed control system, plug and play.
The sampling rate can be adjusted from 10Hz to 100Hz to meet different response speed requirements.
Adopting conformal coating PCB, moisture-proof, corrosion-resistant, and adaptable to harsh environments.
Suitable for industries such as papermaking, electricity, chemical, mining, water treatment, etc.
ending
METSO A413110, with its 8-channel universal input, 16 bit high-precision acquisition, and wide temperature design, has become a reliable analog signal acquisition module choice in the Meizuo DCS system.
Metso A413110印刷电路板 产品展示
