Siemens 6DD1642-0BC0模拟输出模块 PDF资料
1.产 品 资 料 介 绍：
Siemens 6DD1642-0BC0 是西门子 SIMADYN D 系列的一款模拟输出模块，专为大型工业传动及自动化控制系统设计。
中间15个特点
Siemens 6DD1642-0BC0 提供4路模拟量输出通道。
输出信号范围支持 ±10V 和 ±20mA，可灵活选择。
该模块分辨率为12位，满足常规工业控制需求。
每路输出均配备电气隔离，减少通道间干扰。
转换时间约为1.5ms，响应速度较快。
该模块具备短路保护功能，防止输出端意外损坏。
负载能力为电压输出时最大10mA，电流输出时最大500Ω。
模块自带诊断功能，可实时监测输出状态。
工作电压为5V DC（背板供电）和24V DC（负载供电）。
工作温度范围为0至55摄氏度，适应标准工业环境。
模块尺寸为233mm × 160mm × 40mm，符合SIMADYN D标准规格。
采用24针D-sub插座作为对外接口，连接可靠。
Siemens 6DD1642-0BC0 与SIMADYN D系列CPU及I/O模块深度兼容。
该模块用于驱动变频器、伺服驱动器及执行机构等设备。
目前已停产，但常见于旧型号传动系统及改造维修项目中。
结尾
凭借4通道隔离输出、12位分辨率以及稳定的负载能力，Siemens 6DD1642-0BC0 成为SIMADYN D传动控制系统中模量信号输出的可靠选择。
