DSQC332A 3HAC17973-1输入/输出模块 PDF资料
1.产 品 资 料 介 绍：
ABB DSQC332A（3HAC17973-1）是ABB机器人IRC5/S4C+控制系统专用的数字量I/O模块，采用继电器输出设计，用于机器人与外围设备的信号交互。
中间15个特点
DSQC332A（3HAC17973-1）具备16路数字量输入通道。
该模块同时提供16路数字量输出通道。
输入信号为24V DC，支持PNP/NPN切换。
输入阈值高电平≥18V，低电平≤5V。
输出类型为干接点继电器，无极性。
触点容量为2A/24V DC（阻性负载）。
DSQC332A（3HAC17973-1）输入采用光电隔离，抗干扰能力强。
输出采用继电器隔离，与系统电路完全隔离。
每路输入/输出均有独立LED状态指示灯。
该模块适配ABB IRC5和S4C+机器人控制器。
重量约0.545kg，设计紧凑。
尺寸约100×75×25mm，节省安装空间。
支持标准DIN导轨安装，便于集成。
DSQC332A（3HAC17973-1）每通道独立短路保护。
该型号目前已停产，仅二手/翻新/库存备件流通。
结尾
DSQC332A（3HAC17973-1）以16入16出的继电器隔离设计，成为IRC5/S4C+机器人系统中可靠的外围信号交互模块。
DSQC332A 3HAC17973-1输入/输出模块 英文介绍
ABB DSQC332A (3HAC17973-1) is a digital I/O module dedicated to the ABB robot IRC5/S4C+control system. It adopts a relay output design and is used for signal interaction between the robot and peripheral devices.
15 characteristics in the middle
DSQC332A (3HAC17973-1) has 16 digital input channels.
This module provides 16 digital output channels simultaneously.
The input signal is 24V DC and supports PNP/NPN switching.
Input threshold high level ≥ 18V, low level ≤ 5V.
The output type is a dry contact relay with no polarity.
The contact capacity is 2A/24V DC (resistive load).
The DSQC332A (3HAC17973-1) input adopts optoelectronic isolation, with strong anti-interference ability.
The output adopts relay isolation and is completely isolated from the system circuit.
Each input/output has an independent LED status indicator light.
This module is compatible with ABB IRC5 and S4C+robot controllers.
Weighing approximately 0.545kg, the design is compact.
The size is approximately 100 × 75 × 25mm, saving installation space.
Supports standard DIN rail installation for easy integration.
DSQC332A (3HAC17973-1) has independent short-circuit protection for each channel.
This model is currently discontinued and only second-hand/refurbished/inventory spare parts are in circulation.
ending
The DSQC332A (3HAC17973-1) is designed with 16 in 16 out relay isolation, making it a reliable peripheral signal interaction module in the IRC5/S4C+robot system.
DSQC332A 3HAC17973-1输入/输出模块 产品展示
