YASKAWA JANCD-XIO01电路板 PDF资料

1.产 品 资 料 介 绍：

JANCD-XIO01是日本安川电机公司生产的一款高性能工业I/O电路板，主要作为安川机器人和运动控制系统的核心信号交互模块，专为工业自动化领域的数字量与模拟量信号处理而设计。

产品特点：

1. 产品类型为工业I/O板卡，适配安川XRC机器人控制器及MP2000系列运动控制器

2. 数字量输入通道16至40点，支持NPN/PNP自适应，输入电压DC12-24V

3. 数字量输出通道16至40点，晶体管输出，每通道电流0.5A

4. 模拟量输入通道4个，用于采集传感器模拟信号

5. 输入响应时间不超过1毫秒，输出延迟不超过0.5毫秒，满足高速控制需求

6. 所有I/O通道均配备光电隔离，隔离电压不低于2500V AC

7. 通信接口支持MECHATROLINK-III实时同步总线，I/O与伺服轴同步刷新

8. 亦支持RS-485 Modbus及CC-LINK现场总线协议

9. 工作电压DC24V，功耗约10W，由控制器背板或外部供电

10. 工作温度范围0°C至55°C，存储温度零下20°C至70°C

11. 防护等级IP20，适用于标准工业控制柜内安装

12. 板载LED状态指示灯，实时显示电源、通信及各通道工作状态

13. 内置过流、短路保护功能，防止外部负载异常损坏电路

14. 安装方式为标准DIN导轨或XRC控制器机箱插槽

15. 广泛应用于焊接机器人、装配线、数控机床、包装机械等自动化设备

结尾：
JANCD-XIO01电路板以其高速响应、光电隔离抗干扰和MECHATROLINK-III总线同步能力，成为安川机器人及运动控制系统中的关键I/O组件。该模块广泛应用于汽车制造、电子装配、包装机械等工业自动化领域，为设备提供稳定可靠的信号采集与控制输出。

YASKAWA JANCD-XIO01电路板 英文介绍

JANCD-XIO01 is a high-performance industrial I/O circuit board produced by Yaskawa Electric Corporation in Japan. It is mainly used as the core signal interaction module for Yaskawa robots and motion control systems, designed specifically for digital and analog signal processing in the field of industrial automation.

Product Features:

The product type is industrial I/O board, compatible with Yaskawa XRC robot controller and MP2000 series motion controller

Digital input channels from 16 to 40 points, supporting NPC/PNP adaptive, input voltage DC12-24V

Digital output channel 16 to 40 points, transistor output, current 0.5A per channel

Four analog input channels are used to collect sensor analog signals

Input response time not exceeding 1 millisecond, output delay not exceeding 0.5 milliseconds, meeting high-speed control requirements

All I/O channels are equipped with optoelectronic isolation, with an isolation voltage of not less than 2500V AC

The communication interface supports MECHATROLINK-III real-time synchronization bus, and I/O and servo axis synchronization refresh

Also supports RS-485 Modbus and CC-LINK fieldbus protocols

Working voltage DC24V, power consumption about 10W, powered by controller backplane or external source

Working temperature range: 0 ° C to 55 ° C, storage temperature: -20 ° C to 70 ° C

Protection level IP20, suitable for installation inside standard industrial control cabinets

Onboard LED status indicator light, real-time display of power, communication, and channel working status

Built in overcurrent and short circuit protection functions to prevent external load abnormalities from damaging the circuit

The installation method is standard DIN rail or XRC controller chassis slot

Widely used in automation equipment such as welding robots, assembly lines, CNC machine tools, packaging machinery, etc

ending:

The JANCD-XIO01 circuit board has become a key I/O component in Yaskawa robots and motion control systems due to its high-speed response, optoelectronic isolation anti-interference, and MECHATROLINK-III bus synchronization capability. This module is widely used in industrial automation fields such as automobile manufacturing, electronic assembly, and packaging machinery, providing stable and reliable signal acquisition and control output for equipment.

YASKAWA JANCD-XIO01电路板 产品展示
