PM3398BP-6-1-3-E电源模块 PDF资料

1.产 品 资 料 介 绍：

PIONEER MAGNETICS PM3398BP-6-1-3-E 电源模块

开头：
PM3398BP-6-1-3-E是美国先锋磁电公司生产的一款高性能三相工业级电源模块，属于PM3398B系列，专为工业自动化、伺服系统、PLC及关键设备供电而设计。

产品特点：

1. 产品类型为三相工业级PFC电源模块，支持单相与三相兼容输入

2. 输入电压范围340-480V AC，频率47-63Hz，适应宽电压波动工况

3. 输出功率约1500W，输出电压56V DC，额定电流26.8A

4. 功率因数不低于0.99，转换效率不低于90%，具备高能效特性

5. 采用高效PFC拓扑结构，具备高功率密度设计

6. 负载调节精度不超过±1%，输出电压稳定可靠

7. 纹波噪声不超过50mVpp，适配精密电子负载需求

8. 支持N+1并联冗余配置，实现热备份与均流功能

9. 内置过压、过流、过温、短路、输入欠压等多重保护功能

10. 采用强制风冷散热方式，支持满功率连续运行

11. 工作温度范围0°C至50°C，存储温度零下40°C至85°C

12. 防护等级IP20，适用于标准工业控制柜内安装

13. 平均无故障时间不低于50万小时，具备高可靠性

14. 安全认证包括CE、UL、CSA、RoHS，符合国际标准

15. 广泛应用于工业自动化、伺服驱动、运动控制、通信设备等领域

结尾：
PM3398BP-6-1-3-E电源模块以其高功率密度、PFC高效拓扑和全面的保护功能，成为先锋磁电工业电源产品线中的经典型号。该模块广泛应用于伺服系统、PLC、运动控制及关键设备供电场景，为严苛工业环境提供稳定可靠的直流电力保障。

PM3398BP-6-1-3-E电源模块 英文介绍

PIONEER MAGNETICS PM3398BP-6-1-3-E power module

start:

PM3398BP-6-1-3-E is a high-performance three-phase industrial grade power module produced by Pioneer Magnetoelectric Company in the United States. It belongs to the PM3398B series and is designed specifically for powering industrial automation, servo systems, PLCs, and critical equipment.

Product Features:

The product type is a three-phase industrial grade PFC power module that supports single-phase and three-phase compatible inputs

Input voltage range 340-480V AC, frequency 47-63Hz, suitable for wide voltage fluctuation conditions

Output power of approximately 1500W, output voltage of 56V DC, rated current of 26.8A

Power factor not less than 0.99, conversion efficiency not less than 90%, with high energy efficiency characteristics

Adopting an efficient PFC topology structure with high power density design

The load regulation accuracy does not exceed ± 1%, and the output voltage is stable and reliable

Ripple noise not exceeding 50mVpp, suitable for precision electronic load requirements

Support N+1 parallel redundant configuration to achieve hot backup and current sharing functions

Built in multiple protection functions such as overvoltage, overcurrent, overtemperature, short circuit, and input undervoltage

Adopting forced air cooling heat dissipation method, supporting continuous operation at full power

Working temperature range: 0 ° C to 50 ° C, storage temperature: -40 ° C to 85 ° C

Protection level IP20, suitable for installation inside standard industrial control cabinets

The average time between failures is not less than 500000 hours, with high reliability

Safety certifications include CE, UL, CSA, RoHS, and comply with international standards

Widely used in industrial automation, servo drive, motion control, communication equipment and other fields

ending:

The PM3398BP-6-1-3-E power module has become a classic model in the Pioneer Magnetoelectric Industrial Power Product Line due to its high power density, PFC efficient topology, and comprehensive protection functions. This module is widely used in servo systems PLC、 Motion control and key equipment power supply scenarios provide stable and reliable DC power guarantee for harsh industrial environments.

PM3398BP-6-1-3-E电源模块 产品展示
