1.产 品 资 料 介 绍：

IC693MDL740电源转换器

开头：
IC693MDL740是美国GE Fanuc公司生产的一款数字量输出模块，属于Series 90-30可编程逻辑控制器平台，专为工业自动化系统中直流负载设备的控制而设计。

产品特点：

1. 产品类型为16点正逻辑数字量输出模块，属于GE Fanuc Series 90-30 PLC系列

2. 输出点数16个，分为2组，每组8个通道，配备共同输出端子

3. 输出电压范围12至24V DC，额定电压12V或24V DC，兼容正负20%波动

4. 输出电流每通道0.5安培，每组公共端最大电流2安培

5. 输出方式为正逻辑，从模块公共端向负载提供电流

6. 浪涌电流承受能力4.78安培，持续10毫秒

7. 开关响应时间ON和OFF均为2毫秒，满足快速控制需求

8. 现场侧与逻辑侧隔离电压1500伏，组间隔离500伏

9. 从背板5V总线取电，所有输出导通时最大功耗110毫安

10. 配备16个绿色LED指示灯，每通道独立显示开关状态

11. 工作温度范围0°C至60°C，存储温度零下40°C至85°C

12. 相对湿度5%至95%，非冷凝环境适应性强

13. 防护等级IP20，适用于标准工业控制柜内安装

14. 支持热插拔功能，需配合IC693CHS398底座使用

15. 产品已停产，市场上仍有翻新和二手件流通

结尾：
IC693MDL740数字量输出模块以其16点高密度输出、12-24V DC宽电压兼容性和源型正逻辑输出特性，成为GE Fanuc Series 90-30 PLC系统中控制直流负载设备的可靠选择。该模块广泛应用于制造业生产线、过程自动化、物料搬运系统及基础设施控制等领域。

IC693MDL740电源转换器 英文介绍

IC693MDL740 power converter

start:

IC693MDL740 is a digital output module produced by GE Fanuc in the United States. It belongs to the Series 90-30 programmable logic controller platform and is designed specifically for controlling DC load equipment in industrial automation systems.

Product Features:

The product type is a 16 point positive logic digital output module, belonging to the GE Fanuc Series 90-30 PLC series

16 output points, divided into 2 groups of 8 channels each, equipped with a common output terminal

Output voltage range 12 to 24V DC, rated voltage 12V or 24V DC, compatible with positive and negative 20% fluctuations

Output current of 0.5 amperes per channel, maximum common terminal current of 2 amperes per group

The output mode is positive logic, providing current from the module common terminal to the load

Surge current withstand capacity of 4.78 amperes for 10 milliseconds

The response time for both ON and OFF switches is 2 milliseconds, meeting the requirement for fast control

The isolation voltage between the on-site side and the logic side is 1500 volts, and the isolation between groups is 500 volts

Power is taken from the 5V bus on the backplane, with a maximum power consumption of 110mAh when all outputs are conducting

Equipped with 16 green LED indicator lights, each channel independently displays the switch status

Working temperature range: 0 ° C to 60 ° C, storage temperature: -40 ° C to 85 ° C

Relative humidity ranging from 5% to 95%, with strong adaptability to non condensing environments

Protection level IP20, suitable for installation inside standard industrial control cabinets

Supports hot swappable function, needs to be used in conjunction with IC693CHS398 base

The product has been discontinued, but there are still refurbished and second-hand parts circulating in the market

ending:

The IC693MDL740 digital output module has become a reliable choice for controlling DC load equipment in GE Fanuc Series 90-30 PLC systems due to its 16 point high-density output, 12-24V DC wide voltage compatibility, and source type positive logic output characteristics. This module is widely used in manufacturing production lines, process automation, material handling systems, and infrastructure control.

IC693MDL740电源转换器 产品展示
