Yaskawa JACP-317800输入输出模块 PDF资料
1.产 品 资 料 介 绍：
安川JACP-317800是一款高性能逻辑输入输出模块，隶属于安川CP-317系列PLC系统，专为工业自动化领域的数字信号采集与控制而设计。
产品特点：
产品类型为逻辑输入输出模块，作为PLC与现场设备之间的信号接口
模块重量仅0.3公斤，结构轻巧便于安装
外形尺寸约120mm×70mm×35mm，紧凑设计节省控制柜空间
输入点数8路，用于接收传感器、开关等现场设备信号
输出点数8路，用于发送控制信号至执行器、指示灯等设备
输入电压24V DC，符合工业控制标准电源规范
输出电压24V DC，每通道输出电流0.5A
高速数据处理能力，信号处理时间达微秒级，确保实时控制
数据传输速率1.5 Mbps，保障PLC与现场设备高效通信
工作温度范围-20°C至+60°C，适应多种工业环境
防护等级IP20，适用于标准工业控制柜内安装
安装方式为标准35mm DIN导轨安装，便于系统集成
支持梯形图逻辑和C语言编程，配置工具直观易用
内置过流、过压、过热等多重保护功能
平均无故障时间达400,000小时，具有高可靠性
结尾：
安川JACP-317800输入输出模块以其高速响应、高可靠性和紧凑设计，成为安川驱动与控制系统中的关键信号接口设备，适用于机械制造、能源、物流等工业自动化领域的高速逻辑控制应用。
Yaskawa JACP-317800输入输出模块 英文介绍
Yaskawa JACP-317800 is a high-performance logic input/output module belonging to the Yaskawa CP-317 series PLC system, designed specifically for digital signal acquisition and control in the field of industrial automation.
Product Features:
The product type is a logic input/output module, which serves as a signal interface between PLC and field devices
The module weighs only 0.3 kilograms, with a lightweight structure that is easy to install
The external dimensions are approximately 120mm x 70mm x 35mm, with a compact design that saves control cabinet space
8 input points for receiving signals from on-site devices such as sensors and switches
8 output points, used to send control signals to actuators, indicator lights, and other devices
Input voltage 24V DC, in compliance with industrial control standard power supply specifications
Output voltage 24V DC, output current 0.5A per channel
High speed data processing capability, signal processing time up to microseconds, ensuring real-time control
Data transmission rate of 1.5 Mbps ensures efficient communication between PLC and on-site equipment
Working temperature range -20 ° C to+60 ° C, suitable for various industrial environments
Protection level IP20, suitable for installation inside standard industrial control cabinets
The installation method is standard 35mm DIN rail installation, which facilitates system integration
Support ladder diagram logic and C language programming, with intuitive and easy-to-use configuration tools
Built in multiple protection functions such as overcurrent, overvoltage, and overheating
The average time between failures reaches 400000 hours, with high reliability
ending:
The Yaskawa JACP-317800 input/output module, with its high-speed response, high reliability, and compact design, has become a key signal interface device in Yaskawa drive and control systems, suitable for high-speed logic control applications in industrial automation fields such as mechanical manufacturing, energy, and logistics.
Yaskawa JACP-317800输入输出模块 产品展示
