6GK1105-2AA10工业以太网模块 PDF资料
1.产 品 资 料 介 绍：
6GK1105-2AA10 是西门子 SIMATIC NET 系列的 OSM ITP62 光学交换模块，配备光纤端口和 ITP 端口，适用于构建工业以太网骨干网络。该产品已于2023年8月停产。
核心产品特点
端口配置：2个BFOC光纤端口，6个ITP端口。
光纤端口速率100Mbit/s，多模光纤最远传输3公里。
支持24V DC冗余电源输入，带状态监控触点。
支持CLI、Web管理、SNMP、端口镜像等网管功能。
集成冗余管理器，支持HRP和MRP环网冗余，自愈时间约0.3秒。
工作电压18-32V DC，额定24V DC。
工作温度0℃至60℃。
防护等级IP20，需安装在控制柜内。
支持DIN导轨安装、壁挂安装或19英寸机架安装。
尺寸217×161×69mm，重量约1.4kg。
通过ABS、BV、DNV等多家船级社认证，适用于船舶及海上平台。
具备UL、CSA、FM防爆区认证。
适用于自动化生产线骨干网络、智能工厂、交通运输等场景。
结尾
该模块以光纤与ITP混合端口、环网冗余和船级社认证为特点，适用于高可靠性工业网络。
6GK1105-2AA10工业以太网模块 英文介绍
6GK1105-2AA10 is an OSM ITP62 optical switching module from Siemens SIMATIC NET series, equipped with fiber optic ports and ITP ports, suitable for building industrial Ethernet backbone networks. This product was discontinued in August 2023.
Core product features
Port configuration: 2 BFOC fiber ports, 6 ITP ports.
The fiber port speed is 100Mbit/s, and multimode fiber can transmit up to 3 kilometers.
Supports 24V DC redundant power input with status monitoring contacts.
Support CLI, web management SNMP、 Port mirroring and other network management functions.
Integrated redundancy manager, supporting HRP and MRP ring network redundancy, with a self-healing time of approximately 0.3 seconds.
Working voltage 18-32V DC, rated 24V DC.
The working temperature ranges from 0 ℃ to 60 ℃.
The protection level is IP20 and it needs to be installed inside the control cabinet.
Supports DIN rail installation, wall mounting, or 19 inch rack mounting.
Size 217 × 161 × 69mm, weight approximately 1.4kg.
Certified by multiple classification societies such as ABS, BV, DNV, etc., it is suitable for ships and offshore platforms.
Has UL, CSA, FM explosion-proof zone certification.
Suitable for scenarios such as backbone networks of automated production lines, smart factories, and transportation.
ending
This module is characterized by fiber optic and ITP hybrid ports, ring network redundancy, and classification society certification, and is suitable for high reliability industrial networks.
6GK1105-2AA10工业以太网模块 产品展示
