PC10021位置控制器电源模块 PDF资料
1.产 品 资 料 介 绍：
PC10021 是横河（Yokogawa）Fineserv 系列双轴位置控制器，集成电源模块功能，为伺服电机控制系统提供精准定位与稳定供电。
核心产品特点
控制轴数：2轴，支持双轴独立控制与多轴同步运动。
控制模式：支持位置控制、速度控制、扭矩控制三种模式。
输入指令：兼容脉冲+方向、CW/CCW脉冲指令，最高脉冲频率500kHz。
电源输入：100-240V AC，50/60Hz，最大功耗70VA。
电源输出：5V DC/5A和24V DC/0.7A，可作为电源模块为外部设备供电。
定位精度高，脉冲指令响应迅速，适配电子制造等高精度设备。
内置多种运动控制算法，支持直线、圆弧等轨迹控制。
保护功能完善，具备过流、过压、过热、位置超差保护。
紧凑型设计，尺寸约220mm×160mm×100mm，重量约3.2kg。
防护等级IP20，适用于安装在控制柜内。
工作温度范围0℃至40℃，满足一般工业环境需求。
需配套Fineserv MK II电源使用，电源电压范围100-240V AC。
适用于半导体晶圆分选机、电子元件插件机、自动化装配设备等场景。
结尾
该控制器是横河Fineserv系列双轴伺服定位的核心部件，集位置控制与电源输出于一体，以高精度、多模式控制和紧凑设计，广泛应用于半导体、电子制造等行业的精密自动化设备。
PC10021位置控制器电源模块 英文介绍
PC1021 is a Yokogawa Fineservo series dual axis position controller that integrates power module functionality to provide precise positioning and stable power supply for servo motor control systems.
Core product features
Control axis number: 2 axes, supporting dual axis independent control and multi axis synchronous motion.
Control mode: Supports three modes: position control, speed control, and torque control.
Input command: Compatible with pulse+direction and CW/CCW pulse commands, with a maximum pulse frequency of 500kHz.
Power input: 100-240V AC, 50/60Hz, maximum power consumption 70VA.
Power output: 5V DC/5A and 24V DC/0.7A, can be used as a power module to supply power to external devices.
High positioning accuracy, rapid response to pulse commands, suitable for high-precision equipment such as electronic manufacturing.
Built in multiple motion control algorithms, supporting trajectory control such as straight lines and arcs.
The protection function is complete, with overcurrent, overvoltage, overheating, and position out of tolerance protection.
Compact design, with dimensions of approximately 220mm × 160mm × 100mm and a weight of approximately 3.2kg.
Protection level IP20, suitable for installation inside control cabinets.
The working temperature range is from 0 ℃ to 40 ℃, which meets the requirements of general industrial environments.
Fineservo MK II power supply is required, with a voltage range of 100-240V AC.
Suitable for scenarios such as semiconductor wafer sorting machines, electronic component insertion machines, and automated assembly equipment.
ending
This controller is the core component of Yokogawa Fineservo series dual axis servo positioning, integrating position control and power output. With high precision, multi-mode control and compact design, it is widely used in precision automation equipment in industries such as semiconductor and electronic manufacturing.
PC10021位置控制器电源模块 产品展示
