Rexroth DKC03.3-040-7-FW伺服驱动器  PDF资料

1.产 品 资 料 介 绍：

Rexroth DKC03.3-040-7-FW 是博世力士乐 Indramat 系列的一款高性能数字伺服驱动器，属于 EcoDrive 03 系列，专为要求高动态响应和高精度定位的中等功率工业自动化场景而设计。

1. 额定电流：连续输出电流为40A，峰值输出电流可达80A，满足中等负载驱动需求。

2. 电压输入：支持三相200-480V AC宽电压输入，频率50-60Hz，适应全球多种工业电网。

3. 直流母线电压：标称DC 700V，在高加减速循环期间实现高电压吞吐量。

4. 控制电压：需外部DC 24V控制电源供电，功耗约21W。

5. 通信接口：集成PROFIBUS-DP现场总线接口，方便与上位机通信。

6. 输出能力：最大输出电压800V，最大输出频率1000Hz，动态响应优异。

7. 控制模式：支持位置控制、速度控制、转矩控制三环闭环，可灵活切换。

8. FW固件标识：“-FW”后缀表示固件已包含在模块中，无需单独购买固件卡。

9. 冷却方式：内置强制风冷，支持满负荷连续运行。

10. 诊断功能：前面板集成状态指示灯，便于快速查看运行状态。

11. 多重保护：内置过压、欠压、过流、过载、过热、编码器断线等全面保护功能。

12. 工作温度：额定数据下0℃至+45℃，降额使用可达+55℃。

13. 防护等级：IP20，适合安装于通风良好的控制柜内。

结尾

综上所述，Rexroth DKC03.3-040-7-FW 伺服驱动器具备40A额定电流、PROFIBUS通信、FW固件集成及全面保护功能，是中功率、高精度运动控制场景的理想驱动解决方案。

Rexroth  DKC02.3-200-7-FW伺服驱动器  英文介绍

Rexroth DKC03.3-040-7-FW is a high-performance digital servo drive from Bosch Rexroth Indramat series, belonging to EcoDrive 03 series, designed for medium power industrial automation scenarios that require high dynamic response and high-precision positioning.

Rated current: The continuous output current is 40A, and the peak output current can reach 80A, meeting the requirements of medium load driving.

Voltage input: Supports three-phase 200-480V AC wide voltage input, frequency 50-60Hz, suitable for various industrial power grids worldwide.

DC bus voltage: nominal DC 700V, achieving high voltage throughput during high acceleration and deceleration cycles.

Control voltage: requires an external DC 24V control power supply, with a power consumption of approximately 21W.

Communication interface: Integrated PROFIBUS-DP fieldbus interface for convenient communication with the upper computer.

Output capability: Maximum output voltage of 800V, maximum output frequency of 1000Hz, excellent dynamic response.

Control mode: Supports position control, speed control, and torque control in a three loop closed-loop system, which can be flexibly switched.

FW firmware identifier: The suffix "- FW" indicates that the firmware is already included in the module and does not require a separate firmware card purchase.

Cooling method: Built in forced air cooling, supporting continuous operation at full load.

Diagnostic function: The front panel integrates status indicator lights for quick viewing of operating status.

Multiple protection: Built in comprehensive protection functions such as overvoltage, undervoltage, overcurrent, overload, overheating, and encoder disconnection.

Working temperature: 0 ℃ to+45 ℃ under rated data, and up to+55 ℃ for derating use.

Protection level: IP20, suitable for installation in well ventilated control cabinets.

ending

In summary, the Rexroth DKC03.3-040-7-FW servo drive has a rated current of 40A, PROFIBUS communication, FW firmware integration, and comprehensive protection functions, making it an ideal drive solution for medium power, high-precision motion control scenarios.

Rexroth DKC03.3-040-7-FW伺服驱动器  产品展示
