Rexroth DKC02.3-200-7-FW伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
Rexroth DKC02.3-200-7-FW 是博世力士乐 Indramat 系列的高性能数字伺服驱动器，专为高动态响应的工业自动化场景设计。
大电流输出：额定100A，峰值200A，满足高负载需求。
宽压输入：支持200-480V AC，适应全球电网。
SERCOS通信：光纤接口，抗干扰强，支持多轴同步。
固件模块化：“FW”后缀表示固件可单独更换升级。
强制风冷：内置风扇，支持满负荷连续运行。
多控制模式：支持位置、速度、转矩控制，可灵活切换。
数码管诊断：前面板显示故障代码，快速定位异常。
多重保护：内置过流、过载、短路保护，符合SIL 2标准。
工作温度：最高40℃（额定），降额可用至55℃。
防护等级：IP20，适合安装于控制柜内。
开关频率：支持4kHz或8kHz可选。
高母线电压：DC 700V，改善高惯性负载响应。
适用场景：机床、包装、印刷、机器人等。
结尾
综上所述，该驱动器具备大电流、光纤通信、模块化固件及可靠保护等特点，是高负载高精度运动控制的理想选择。
Rexroth DKC02.3-200-7-FW伺服驱动器 英文介绍
Rexroth DKC02.3-200-7-FW is a high-performance digital servo drive from Bosch Rexroth Indramat series, designed specifically for high dynamic response industrial automation scenarios.
High current output: rated 100A, peak 200A, meets high load requirements.
Wide voltage input: Supports 200-480V AC and adapts to the global power grid.
SERCOS communication: fiber optic interface, strong anti-interference, supports multi axis synchronization.
Firmware modularization: The suffix "FW" indicates that the firmware can be replaced and upgraded separately.
Forced air cooling: Equipped with a built-in fan that supports continuous operation at full load.
Multi control mode: supports position, speed, and torque control, and can be flexibly switched.
Digital tube diagnosis: The front panel displays a fault code, quickly locating the abnormality.
Multiple protection: Built in overcurrent, overload, and short circuit protection, compliant with SIL 2 standard.
Working temperature: up to 40 ℃ (rated), can be reduced to 55 ℃.
Protection level: IP20, suitable for installation inside control cabinets.
Switching frequency: Supports 4kHz or 8kHz optional.
High bus voltage: DC 700V, improves high inertia load response.
Applicable scenarios: machine tools, packaging, printing, robots, etc.
ending
In summary, this driver has the characteristics of high current, fiber optic communication, modular firmware, and reliable protection, making it an ideal choice for high load and high-precision motion control.
Rexroth DKC02.3-200-7-FW伺服驱动器 产品展示
