SVT57BL03-60V-50167BL01伺服电机 PDF资料
1.产 品 资 料 介 绍：
SVT57BL03-60V-50167BL01 是意大利 SERVOTECNICA 公司生产的一款 57mm 法兰无刷伺服电机，采用 60V 低压供电设计，专为空间紧凑、需要高速高精度定位的工业自动化场景而打造。
品牌归属：意大利 SERVOTECNICA（伺服泰克）原装生产，代表欧洲精密传动技术。
电机类型：三相无刷直流伺服电机，永磁转子结构。
额定电压：60V DC 直流供电，兼顾安全性，适配电池或低压供电系统。
额定功率：138W（也有资料显示约 167W），满足中小功率驱动需求。
额定扭矩：0.33 N·m，峰值扭矩可达 1.0 N·m（持续时间≤3秒）。
额定转速：5000 RPM，最高转速可达 6000 RPM，动态响应优异。
扭矩常数：0.065 N·m/A，反电动势常数 4.8 Vrms/KRPM。
绕组参数：线-线电阻 0.45Ω，线-线电感 1.5mH。
峰值电流：峰值电流可达 16A，满足瞬时大扭矩输出需求。
编码器配置：适配 H40-6-0500VL 增量编码器（500线，差分输出），支持位置闭环控制。
防护等级：标准 IP40，可选 IP54 定制版本，适应一般工业环境。
尺寸重量：外径 57mm × 长度约 110mm，重量约 1.2kg，结构紧凑。
适用场景：广泛用于机器人关节、小型自动化设备、CNC 机床、精密定位机构等。
结尾
综上所述，SVT57BL03-60V-50167BL01 伺服电机具备低压安全、高速高响应、结构紧凑及精度高等特点，是小型自动化设备精密驱动的理想选择
SVT57BL03-60V-50167BL01伺服电机 英文介绍
SVT57BL03-60V-50167BL01 is a 57mm flange brushless servo motor produced by SERVOTENICA, an Italian company. It is designed with a 60V low-voltage power supply and is specifically designed for industrial automation scenarios that require compact space and high-speed high-precision positioning.
Brand affiliation: Produced by SERVOTENICA from Italy, representing European precision transmission technology.
Motor type: Three phase brushless DC servo motor, permanent magnet rotor structure.
Rated voltage: 60V DC power supply, considering safety, compatible with batteries or low-voltage power supply systems.
Rated power: 138W (some data shows about 167W), meeting the needs of small and medium power drives.
Rated torque: 0.33 N · m, peak torque can reach 1.0 N · m (duration ≤ 3 seconds).
Rated speed: 5000 RPM, maximum speed can reach 6000 RPM, excellent dynamic response.
Torque constant: 0.065 N · m/A, back electromotive force constant: 4.8 Vrms/KRPM.
Winding parameters: wire to wire resistance of 0.45 Ω, wire to wire inductance of 1.5mH.
Peak current: The peak current can reach 16A, meeting the demand for instantaneous high torque output.
Encoder configuration: Suitable for H40-6-0500VL incremental encoder (500 lines, differential output), supporting position closed-loop control.
Protection level: standard IP40, optional IP54 customized version, suitable for general industrial environments.
Size and weight: outer diameter 57mm x length approximately 110mm, weight approximately 1.2kg, compact structure.
Applicable scenarios: Widely used in robot joints, small automation equipment, CNC machine tools, precision positioning mechanisms, etc.
ending
In summary, the SVT57BL03-60V-50167BL01 servo motor has the characteristics of low voltage safety, high speed and high response, compact structure, and high precision, making it an ideal choice for precision driving of small automation equipment
SVT57BL03-60V-50167BL01伺服电机 产品展示
