EBERLE A-42/051442000000印刷电路板 PDF资料
1.产 品 资 料 介 绍：
EBERLE A-42/051442000000 是一款专为工业自动化系统设计的印刷电路板，主要承担数字量输出功能，用于驱动外部负载。
输出通道：提供 32 个数字量输出点，可同时控制多个设备。
信号类型：采用晶体管输出形式，响应速度快，适用于高频开关场合。
负载能力：每通道支持 0.5A 的输出电流，可直接驱动小型继电器、指示灯或电磁阀。
电压等级：工作电压为 24V DC，符合工业控制标准。
紧凑尺寸：模块尺寸约为 18×2×14 cm，重量仅 0.167 kg，节省安装空间。
系统集成：作为 Eberle 系统的组件，可与同品牌控制器及 I/O 模块配套使用。
状态指示：板载 LED 指示灯，可实时显示各通道的通断状态。
短路保护：输出回路可能集成过流或短路保护功能，防止损坏。
电气隔离：输出侧与逻辑侧之间设有隔离，保障控制器安全。
快速响应：晶体管输出特性支持高速开关，适用于脉冲控制或定位应用。
宽温适应：设计工作温度范围覆盖工业现场常见环境（如 0℃ 至 55℃）。
易维护：采用可插拔端子或标准化连接器，更换便捷。
兼容性强：与同系列模块协同工作，扩展灵活。
结尾
综上所述，EBERLE A-42/051442000000 作为 32 点数字量输出板卡，具备通道多、响应快、负载能力强等特点，是工业控制系统中驱动执行层设备的理想选择。
EBERLE A-42/051442000000印刷电路板 英文介绍
EBERLE A-42/051442000000 is a printed circuit board designed specifically for industrial automation systems, mainly responsible for digital output functions, used to drive external loads.
Output channel: Provides 32 digital output points that can control multiple devices simultaneously.
Signal type: Adopting transistor output form, fast response speed, suitable for high-frequency switching occasions.
Load capacity: Each channel supports an output current of 0.5A and can directly drive small relays, indicator lights, or solenoid valves.
Voltage level: The working voltage is 24V DC, which complies with industrial control standards.
Compact size: The module size is approximately 18 × 2 × 14 cm, with a weight of only 0.167 kg, saving installation space.
System integration: As a component of the Eberle system, it can be used in conjunction with controllers and I/O modules of the same brand.
Status indication: Onboard LED indicator light, which can display the real-time on/off status of each channel.
Short circuit protection: The output circuit may integrate overcurrent or short circuit protection functions to prevent damage.
Electrical isolation: There is isolation between the output side and the logic side to ensure the safety of the controller.
Fast response: The transistor output characteristics support high-speed switching, suitable for pulse control or positioning applications.
Wide temperature adaptation: The designed working temperature range covers common environments in industrial sites (such as 0 ℃ to 55 ℃).
Easy to maintain: using pluggable terminals or standardized connectors, easy to replace.
Strong compatibility: works in conjunction with modules of the same series, and has flexible expansion.
ending
In summary, EBERLE A-42/051442000000, as a 32-bit digital output board, has the characteristics of multiple channels, fast response, and strong load capacity, making it an ideal choice for driving execution layer equipment in industrial control systems.
