LA7-D3064继电器 PDF资料
1.产 品 资 料 介 绍：
LA7-D3064 是施耐德电气 TeSys 系列中的热过载继电器适配器/底座，主要用于与热过载继电器配合，为电机提供过载、断相等保护功能。以下是该模块的15条主要产品特点：
中间15条特点：
属于施耐德 TeSys Deca 系列，专为电机过载保护设计
适配多种热过载继电器型号，包括 LRD33、LR2D35、LR3D35 等
额定电流适用于 30A 的热过载继电器配置
支持过载保护、相位不平衡保护及断相保护功能
采用双金属片与电子监控技术，通过差动原理实现精准监测
可与施耐德 LC1 系列接触器及 LADN 系列辅助触点模块无缝集成
支持手动复位、自动复位及远程电气复位多种方式
工作温度范围为 -25°C 至 +60°C，环境适应性强
存储温度范围为 -25°C 至 +70°C
防护等级为 IP20，适用于控制柜内标准安装环境
安装方式灵活，支持 35mm DIN 导轨安装或螺钉固定
紧凑设计，尺寸约为 75mm × 10mm × 121mm，重量约 0.37kg
符合 IEC 60947-4-1 等国际标准，具备 CE、UL、CSA 认证
内置故障自诊断功能，可通过辅助触点实时上传异常状态
广泛应用于工业自动化、建筑设备、交通运输等领域的电机保护
结尾（总结）：
总体来看，该适配器作为 TeSys 电机保护系统的重要组成部分，具有兼容性强、保护功能完善、安装灵活等特点，是各类工业电机过载保护应用的可靠基础组件。
LA7-D3064继电器 英文介绍
LA7-D3064 is a thermal overload relay adapter/base in Schneider Electric's TeSys series, mainly used to cooperate with thermal overload relays to provide overload and phase break protection functions for motors. Here are the 15 main product features of this module:
The 15 characteristics in the middle:
Belonging to Schneider TeSys Deca series, specially designed for motor overload protection
Compatible with multiple models of thermal overload relays, including LRD33, LR2D35, LR3D35, etc
Rated current suitable for 30A thermal overload relay configuration
Support overload protection, phase imbalance protection, and phase failure protection functions
Using bimetallic strips and electronic monitoring technology, precise monitoring is achieved through differential principle
Seamless integration with Schneider LC1 series contactors and LADN series auxiliary contact modules
Supports multiple methods including manual reset, automatic reset, and remote electrical reset
The working temperature range is -25 ° C to+60 ° C, with strong environmental adaptability
The storage temperature range is -25 ° C to+70 ° C
The protection level is IP20, suitable for standard installation environment inside the control cabinet
Flexible installation method, supporting 35mm DIN rail installation or screw fixation
Compact design, size approximately 75mm x 10mm x 121mm, weight approximately 0.37kg
Compliant with international standards such as IEC 60947-4-1, with CE, UL, CSA certifications
Built in fault self diagnosis function, which can upload abnormal status in real time through auxiliary contacts
Widely used for motor protection in industrial automation, construction equipment, transportation and other fields
Conclusion:
Overall, as an important component of the TeSys motor protection system, this adapter has the characteristics of strong compatibility, complete protection functions, and flexible installation. It is a reliable basic component for various industrial motor overload protection applications.
LA7-D3064继电器 产品展示
