SIEMENS 6SE7022-6EC61-Z逆变器单元 PDF资料
1.产 品 资 料 介 绍：
SIEMENS 6SE7022-6EC61-Z 是西门子 SIMOVERT MASTERDRIVES 系列中的一款紧凑型逆变器单元，属于 Vector Control 矢量控制系列，适用于三相电机的精确速度与转矩控制应用。以下是该模块的15条主要产品特点：
中间15条特点：
属于 SIMOVERT MASTERDRIVES Vector Control 系列，为紧凑型逆变器单元
部分来源将其归类为 MIDIMASTER VECTOR 系列中型矢量变频器
输入电压为三相 380-480V AC，频率 50/60Hz
额定输出电流为 25.5A
额定输出功率为 11kW
防护等级为 IP20，适用于控制柜内安装
采用矢量控制技术，实现高精度的速度和转矩控制
支持 PROFIBUS 通信协议，可扩展 CBP2 通信模块（G93 选件）
部分配置支持 CANopen 和 PROFINET IO 通信接口
产品生命周期状态为“备件”，已停产需确认库存
冷却方式存在差异描述：有水冷和强制风冷两种说法
输出频率范围可达 0-600Hz 或 0-400Hz，调速范围宽
内置过载保护和短路保护功能，保障设备安全
重量范围约 3.5kg 至 24.5kg（因配置不同有所差异）
适用于机械制造、食品加工、化工、纺织、印刷包装等工业自动化场景
结尾（总结）：
总体来看，该逆变器单元作为 SIMOVERT MASTERDRIVES 矢量控制系列的成员，具有控制精度高、功率适配性强、通信接口灵活等特点，是各类工业电机调速与控制应用的可靠解决方案。
SIEMENS 6SE7022-6EC61-Z逆变器单元 英文介绍
SIEMENS 6SE7022-6EC61-Z is a compact inverter unit in the Siemens SIMOVERT MASTERDRIVES series, belonging to the Vector Control series, suitable for precise speed and torque control applications of three-phase motors. Here are the 15 main product features of this module:
The 15 characteristics in the middle:
Belonging to the SIMOVERT MASTERDRIVES Vector Control series, it is a compact inverter unit
Some sources classify it as a MIDIMASTER VECTOR series medium-sized vector frequency converter
The input voltage is three-phase 380-480V AC, with a frequency of 50/60Hz
The rated output current is 25.5A
The rated output power is 11kW
The protection level is IP20, suitable for installation inside control cabinets
Using vector control technology to achieve high-precision speed and torque control
Supports PROFIBUS communication protocol and expandable CBP2 communication module (G93 option)
Partial configuration supports CANopen and PROFINET IO communication interfaces
The product lifecycle status is "spare parts" and has been discontinued, requiring confirmation of inventory
There are two different cooling methods: water-cooled and forced air-cooled
The output frequency range can reach 0-600Hz or 0-400Hz, and the speed regulation range is wide
Built in overload protection and short circuit protection functions to ensure equipment safety
The weight range is approximately 3.5kg to 24.5kg (varies due to different configurations)
Suitable for industrial automation scenarios such as mechanical manufacturing, food processing, chemical industry, textile, printing and packaging
Conclusion:
Overall, as a member of the SIMOVERT MASTERDRIVES vector control series, this inverter unit has the characteristics of high control accuracy, strong power adaptability, and flexible communication interface. It is a reliable solution for various industrial motor speed regulation and control applications.
SIEMENS 6SE7022-6EC61-Z逆变器单元 产品展示
