SIEMENS 6SE7012-0TP50-Z变频器 PDF资料
1.产 品 资 料 介 绍：
SIEMENS 6SE7012-0TP50-Z 是西门子 SIMOVERT MASTERDRIVES MC 系列中的一款紧凑型变频器，属于运动控制领域的工程型传动产品。以下是该模块的15条主要产品特点：
中间15条特点：
属于 SIMOVERT MASTERDRIVES MC 运动控制系列，为 Compact Plus 紧凑增强书本型变频器
产品生命周期状态为“备件”，已于 2020年9月30日正式停产
官方建议的后续替代型号为 6SE7012-0TP70
额定输出功率为 0.75 kW，适用于小型电机驱动应用
输出额定电流为 2A，部分配置下可扩展至 6A
输入侧为直流供电，电压范围为 510V 至 650V DC，需配套整流单元使用
输出侧为三相交流，电压范围为 380V 至 480V AC，输出频率最高可达 400Hz
采用矢量控制技术，能够实现高精度的速度和转矩控制
支持 V/F 控制方式，适用于风机、泵类等变转矩负载场景
过载能力为 150% 额定电流持续 1 分钟，180% 额定电流持续 3 秒钟
防护等级为 IP20，适用于控制柜内安装
工作温度范围为 -25°C 至 +60°C，环境适应性较强
型号后缀（如 F01、G11、K80、C23 等）代表不同的选装软件或硬件功能模块
重量约为 1.4kg 至 3.0kg，结构紧凑便于机柜安装
支持 PROFIBUS 等工业通信协议，便于与 PLC 等控制系统集成
结尾（总结）：
总体来看，该变频器作为 SIMOVERT MASTERDRIVES 系列的小功率成员，具有控制精度高、结构紧凑、配置灵活等特点，适用于各类需要精确电机控制的工业自动化场景。
SIEMENS 6SE7012-0TP50-Z变频器 英文介绍
SIEMENS 6SE7012-0TP50-Z is a compact frequency converter in the Siemens SIMOVERT MASTERDRIVES MC series, belonging to the engineering transmission product in the field of motion control. Here are the 15 main product features of this module:
The 15 characteristics in the middle:
Belonging to the SIMOVERT MASTERDRIVES MC motion control series, it is a Compact Plus compact enhanced book type frequency converter
The product lifecycle status is "spare parts" and was officially discontinued on September 30, 2020
The official suggested alternative model is 6SE7012-0TP70
Rated output power of 0.75 kW, suitable for small motor drive applications
The rated output current is 2A, and it can be expanded to 6A in some configurations
The input side is powered by DC, with a voltage range of 510V to 650V DC, and requires a matching rectifier unit for use
The output side is three-phase AC, with a voltage range of 380V to 480V AC and an output frequency of up to 400Hz
By adopting vector control technology, high-precision speed and torque control can be achieved
Support V/F control mode, suitable for variable torque load scenarios such as fans and pumps
Overload capacity of 150% rated current for 1 minute, 180% rated current for 3 seconds
The protection level is IP20, suitable for installation inside control cabinets
The working temperature range is -25 ° C to+60 ° C, with strong environmental adaptability
The model suffix (such as F01, G11, K80, C23, etc.) represents different optional software or hardware functional modules
The weight is approximately 1.4kg to 3.0kg, with a compact structure that is easy to install in the cabinet
Supports industrial communication protocols such as PROFIBUS, making it easy to integrate with control systems such as PLC
Conclusion:
Overall, as a low-power member of the SIMOVERT MASTERDRIVES series, this frequency converter has the characteristics of high control accuracy, compact structure, and flexible configuration, and is suitable for various industrial automation scenarios that require precise motor control.
SIEMENS 6SE7012-0TP50-Z变频器 产品展示
