6GK1561-3AA00接口模块 PDF资料
1.产 品 资 料 介 绍：
6GK1561-3AA00 接口模块
开头： 6GK1561-3AA00 是西门子工业通信产品线中的 PROFIBUS 接口模块，型号为 CP 5613 A2，用于将 PCI 总线工控机连接至 PROFIBUS 现场总线网络。
核心特点：
支持 PROFIBUS DP 协议，可作为 DP 主站或从站使用。
采用 PCI 总线接口，适用于标准工控机和台式计算机。
通信速率最高 12 Mbit/s，支持自动速率检测。
配备 9 针 D-Sub 接口，用于连接 PROFIBUS 总线电缆。
支持直接访问双端口 RAM，实现高速数据交换。
提供 Windows 操作系统驱动，兼容常见工控软件。
工作温度范围 0°C 至 55°C，适应常规工业环境。
防护等级 IP20，需安装于工控机机箱内部。
支持多协议操作，可同时运行 DP 和 FDL 协议。
具备诊断功能，可监控总线状态和通信错误。
6GK1561-3AA00 适用于 PC 控制、数据采集和工厂级监控系统。
支持与 S7-300、S7-400 等西门子 PLC 进行 PROFIBUS 通信。
结尾： 总体而言，6GK1561-3AA00 凭借 PCI 总线接口、12 Mbit/s 通信速率和主从站灵活配置，为工控机接入 PROFIBUS 网络提供了可靠高效的解决方案。
6GK1561-3AA00接口模块 英文介绍
6GK1561-3AA00 interface module
Introduction: 6GK1561-3AA00 is a PROFIBUS interface module in Siemens' industrial communication product line, model CP 5613 A2, used to connect PCI bus industrial computers to PROFIBUS fieldbus networks.
Core features:
Supports PROFIBUS DP protocol and can be used as a DP master or slave.
Adopting PCI bus interface, suitable for standard industrial control computers and desktop computers.
The communication rate can reach up to 12 Mbit/s and supports automatic rate detection.
Equipped with a 9-pin D-Sub interface for connecting PROFIBUS bus cables.
Support direct access to dual port RAM for high-speed data exchange.
Provide Windows operating system drivers, compatible with common industrial control software.
The working temperature range is from 0 ° C to 55 ° C, suitable for conventional industrial environments.
The protection level is IP20 and it needs to be installed inside the industrial computer chassis.
Supports multi protocol operations and can run both DP and FDL protocols simultaneously.
Equipped with diagnostic function, it can monitor bus status and communication errors.
6GK1561-3AA00 is suitable for PC control, data acquisition, and factory level monitoring systems.
Supports PROFIBUS communication with Siemens PLCs such as S7-300 and S7-400.
Conclusion: Overall, 6GK1561-3AA00 provides a reliable and efficient solution for industrial control computers to access PROFIBUS networks with its PCI bus interface, 12 Mbit/s communication rate, and flexible configuration of master-slave stations.
6GK1561-3AA00接口模块 产品展示
