140CPU65150处理器模块 PDF资料

1.产 品 资 料 介 绍：

Schneider Electric 140CPU65150是施耐德Modicon Quantum系列的高性能Unity处理器模块，适用于过程控制、机器自动化、交通信号控制等大型工业应用场景。

1. 处理器主频166 MHz，采用RISC架构。

2. 内置768 KB RAM，可通过PCMCIA卡将程序存储扩展至7168 KB。

3. 支持最多31744个离散I/O点和500个模拟I/O点。

4. 最大支持2个本地机架、63个分布式I/O站。

5. 集成以太网TCP/IP、Modbus、Modbus Plus、USB通信接口。

6. 支持高速中断输入、计数、精确时间戳等专用I/O功能。

7. 内置Web服务器功能，支持通过浏览器远程访问和监控。

8. 支持Unity Pro软件编程，兼容梯形图、功能块图等多种语言。

9. 前面板配备LCD显示屏和键盘，便于现场调试和维护。

10. 工作温度范围0~60℃，存储温度-40~85℃。

11. 总线电流需求2160 mA，尺寸符合Quantum标准模块规格。

12. 通过CE、UL、CSA等国际认证，适用于恶劣工业环境。

13. 支持多任务处理，主任务周期1 ms，快速任务周期0.2 ms。

14. 每毫秒可执行约10.28 K条布尔指令。

15. 支持CPU冗余配置，保障系统高可用性。

140CPU65150处理器模块以166 MHz主频、大容量I/O扩展能力和丰富的通信接口，为Modicon Quantum系列提供强大的控制核心。

140CPU65150处理器模块  英文介绍

Schneider Electric 140CPU65150 is a high-performance Unity processor module from Schneider Modicon Quantum series, suitable for large-scale industrial applications such as process control, machine automation, and traffic signal control.

The processor has a clock frequency of 166 MHz and adopts RISC architecture.

Built in 768 KB RAM, program storage can be expanded to 7168 KB through PCMCIA card.

Supports up to 31744 discrete I/O points and 500 analog I/O points.

Supports up to 2 local racks and 63 distributed I/O stations.

Integrated Ethernet TCP/IP, Modbus, Modbus Plus, USB communication interfaces.

Supports specialized I/O functions such as high-speed interrupt input, counting, and precise timestamps.

Built in web server functionality, supporting remote access and monitoring through a browser.

Support Unity Pro software programming, compatible with multiple languages such as ladder diagrams and functional block diagrams.

The front panel is equipped with an LCD display screen and keyboard for easy on-site debugging and maintenance.

The working temperature range is 0-60 ℃, and the storage temperature is -40~85 ℃.

The bus current requirement is 2160 mA, and the size meets the Quantum standard module specifications.

Through international certifications such as CE, UL, CSA, etc., it is suitable for harsh industrial environments.

Support multitasking, with a main task cycle of 1 ms and a fast task cycle of 0.2 ms.

Approximately 10.28 K Boolean instructions can be executed per millisecond.

Support CPU redundancy configuration to ensure high availability of the system.

The 140CPU65150 processor module provides a powerful control core for the Modicon Quantum series with a main frequency of 166 MHz, large capacity I/O expansion capability, and rich communication interfaces.

140CPU65150处理器模块 产品展示
