NSH-12RH齿轮电机 PDF资料
1.产 品 资 料 介 绍：
Bodine Electric NSH-12RH是并励式直流齿轮电机，适用于需要稳定转速和调节特性的工业传动应用。
电压等级115V DC，电流0.33A，功率1/50HP。
采用并励绕组结构，磁场由独立励磁绕组产生。
转速特性较硬，负载变化时转速波动小。
具备良好的调速性能，适合宽范围速度调节。
需要为励磁绕组和电枢分别提供电源。
励磁绕组电阻约1kΩ，需接通直流电才能产生转矩。
电枢绕组电阻较低，由控制器驱动。
不可直接使用永磁电机控制器，需匹配并励电机驱动方式。
典型应用包括传送带、包装设备、医疗仪器等。
属于Bodine早期直流齿轮电机产品线。
齿轮箱与电机集成设计，输出扭矩大。
采用紧凑型结构，便于设备集成。
适用于需要稳定低速运行的场合。
励磁失效时电机无法运转，需注意励磁回路保护。
接线时需区分电枢与励磁绕组，不可接错。
NSH-12RH齿轮电机以并励结构带来的稳定转速特性和良好调速性能，适用于对速度平稳性有要求的直流传动应用。
NSH-12RH齿轮电机 英文介绍
Bodine Electric NSH-12RH is a parallel excited DC gear motor suitable for industrial transmission applications that require stable speed and adjustable characteristics.
Voltage level 115V DC, current 0.33A, power 1/50HP.
Adopting a parallel excitation winding structure, the magnetic field is generated by independent excitation windings.
The speed characteristics are relatively hard, and the speed fluctuation is small when the load changes.
Has good speed regulation performance, suitable for wide range speed regulation.
Power needs to be provided separately for the excitation winding and armature.
The excitation winding has a resistance of about 1k Ω and requires direct current to generate torque.
The resistance of the armature winding is low and is driven by the controller.
Permanent magnet motor controller cannot be directly used, it needs to be matched with parallel excitation motor drive mode.
Typical applications include conveyor belts, packaging equipment, medical instruments, etc.
Belonging to Bodine's early DC gear motor product line.
Integrated design of gearbox and motor, with high output torque.
Adopting a compact structure for easy equipment integration.
Suitable for situations that require stable low-speed operation.
When the excitation fails, the motor cannot operate, and attention should be paid to the protection of the excitation circuit.
When wiring, it is necessary to distinguish between the armature and the excitation winding and not connect them incorrectly.
The NSH-12RH gear motor, with its parallel excitation structure, provides stable speed characteristics and excellent speed regulation performance, making it suitable for DC drive applications that require speed stability.
NSH-12RH齿轮电机 产品展示
