Yokogawa F3PU10-0N电源模块 PDF资料
1.产 品 资 料 介 绍：
Yokogawa F3PU10-0N是横河FA-M3系列PLC的交流电源模块，为CPU及I/O模块提供稳定直流供电。
输入电压AC 100-240V（50/60Hz），允许波动85-264V。
额定输出5V DC/2.0A，功耗35VA。
浪涌电流20A（120V）/45A（240V）。
内置不可更换保险丝，过载时保护电路。
绝缘电阻≥5MΩ（500V DC测试）。
耐压1500V AC（外部端子对FG），漏电流≤3.5mA。
允许瞬时断电时间20ms。
工作温度0-55℃，适应工业环境。
尺寸28.9×100×83.2mm，重量190g。
专用于F3BU04和F3BU06基板。
支持故障信号触点输出，异常时报警。
端子螺丝有0N和0S两种规格，电气性能相同。
防护等级IP20，适用于控制柜内安装。
模块化插槽式设计，安装维护便捷。
通过横河电机严格测试，可靠性高。
F3PU10-0N电源模块以宽电压输入、稳定输出和紧凑尺寸，为FA-M3系列提供可靠的系统供电保障。
Yokogawa F3PU10-0N is an AC power module for Yokogawa FA-M3 series PLC, providing stable DC power supply for CPU and I/O modules.
Input voltage AC 100-240V (50/60Hz), allowable fluctuation 85-264V.
Rated output 5V DC/2.0A, power consumption 35VA.
Surge current of 20A (120V)/45A (240V).
Built in non replaceable fuse, protects the circuit in case of overload.
Insulation resistance ≥ 5M Ω (tested at 500V DC).
Withstand voltage 1500V AC (external terminal to FG), leakage current ≤ 3.5mA.
Allow an instantaneous power outage time of 20ms.
The working temperature is 0-55 ℃, suitable for industrial environments.
Size 28.9 × 100 × 83.2mm, weight 190g.
Specially designed for F3BU04 and F3BU06 substrates.
Support fault signal contact output, alarm in case of abnormality.
There are two specifications of terminal screws, 0N and 0S, with the same electrical performance.
Protection level IP20, suitable for installation inside control cabinets.
Modular slot design, easy to install and maintain.
Through rigorous testing by Yokogawa Electric, the reliability is high.
The F3PU10-0N power module provides reliable system power supply for the FA-M3 series with wide voltage input, stable output, and compact size.
