Yokogawa F3BU06-0N 控制器背板 PDF资料
1.产 品 资 料 介 绍：
Yokogawa F3BU06-0N是横河FA-M3系列PLC的6槽主基板，为CPU、电源及I/O模块提供高速背板总线连接。
配备6个模块插槽，支持1个电源、1个CPU和4个I/O或功能模块。
采用高速专用并行总线，匹配FA-M3系列的高速处理性能。
镀金连接器设计，确保低接触电阻，耐氧化。
后缀“0N”表示标准非隔离安装配置。
绝缘电阻≥10MΩ（500V DC），耐压1500V AC 1分钟。
工作温度0~55℃，适应工业控制柜环境。
功耗低，5V DC下电流消耗约50mA。
尺寸宽245×高130×深18.5mm，重量约0.42kg。
支持面板安装或DIN导轨安装。
材质为工业级增强聚合物与金属合金。
兼容F3PU系列电源模块，电源槽位于最左侧。
支持带电插拔，便于维护。
防护等级IP20，适用于室内控制柜。
扩展基板需选用F3BX系列，F3BU为主基板不可用于扩展。
适配FA-M3/F3BU系列6槽配置中，I/O槽位为5个。
F3BU06-0N基板为FA-M3系统提供紧凑稳定的硬件平台，是构建中型自动化控制系统的可靠基础。
Yokogawa F3BU06-0N is a 6-slot main substrate for Yokogawa FA-M3 series PLC, providing high-speed backplane bus connections for CPU, power supply, and I/O modules.
Equipped with 6 module slots, supporting 1 power supply, 1 CPU, and 4 I/O or functional modules.
Adopting a high-speed dedicated parallel bus, matched with the high-speed processing performance of the FA-M3 series.
Gold plated connector design ensures low contact resistance and oxidation resistance.
The suffix '0N' indicates a standard non isolated installation configuration.
Insulation resistance ≥ 10M Ω (500V DC), withstand voltage 1500V AC for 1 minute.
Working temperature range of 0-55 ℃, suitable for industrial control cabinet environment.
Low power consumption, with a current consumption of approximately 50mA at 5V DC.
The dimensions are 245 in width, 130 in height, and 18.5mm in depth, with a weight of approximately 0.42kg.
Supports panel installation or DIN rail installation.
The material is industrial grade reinforced polymer and metal alloy.
Compatible with F3PU series power modules, the power slot is located on the leftmost side.
Supports live plugging and unplugging for easy maintenance.
Protection level IP20, suitable for indoor control cabinets.
The F3BX series is required for the expansion substrate, and F3BU is not suitable for expansion as the main substrate.
In the FA-M3/F3BU series 6-slot configuration, there are 5 I/O slots available.
The F3BU06-0N substrate provides a compact and stable hardware platform for the FA-M3 system, serving as a reliable foundation for building medium-sized automation control systems.
