JAMSC-B1070寄存器输出模块  PDF资料

1.产 品 资 料 介 绍：

YASKAWA JAMSC-B1070是一款专为Memocon-SC系列PLC设计的数值寄存器输出模块，用于将CPU寄存器中的数字量数据转换为并行数值信号输出至外部设备。

• 属于1000系列I/O模块，适配Memocon-SC的R84H、U84、U845及584等PLC型号

• 单模块占用一个标准插槽，安装方式与离散I/O模块相同

• 支持8个通道的数值输出，通道数量由I/O分配表设定

• 输出数据类型可选BCD码或二进制，支持两种格式混合配置

• BCD格式下，R84H支持3位或10位二进制，其他机型支持4位或16位二进制

• 数值输出采用开集电极输出，耐压30V，灌电流50mA

• 选通信号为开集电极输出，用于通知外部设备锁存当前有效数据

• 选通周期64ms，逻辑为有效低电平

• 外部电路与内部电路之间隔离电压1500V AC，绝缘电阻50MΩ

• 需外接24V DC±2V电源，电流消耗0.2A

• 面板指示灯包括BUS指示灯和FIELD指示灯

• 外部接线距离建议不超过30米

• 接线时需与动力线分开布线，以减少电磁干扰

• 适用于需要将PLC数值数据并行输出到外部仪表或执行器的场景

• 该型号目前已停产，但仍有备件可用于存量系统维护

YASKAWA JAMSC-B1070寄存器输出模块凭借其多通道数值输出能力、BCD/二进制灵活配置及可靠的电气隔离特性，适用于Memocon-SC系列PLC系统升级、备件更换及需要并行数值输出的自动化控制场景

JAMSC-B1070寄存器输出模块 英文介绍

YASKAWA JAMSC-B1070 is a numerical register output module designed specifically for Memocon SC series PLCs, used to convert digital data in CPU registers into parallel numerical signals and output them to external devices.

Belonging to the 1000 series I/O module, compatible with Memocon SC's R84H, U84, U845, 584 and other PLC models

A single module occupies a standard slot and is installed in the same way as discrete I/O modules

Supports numerical output of 8 channels, with the number of channels set by the I/O allocation table

The output data type can be BCD code or binary, and supports mixed configuration of the two formats

In BCD format, R84H supports 3-bit or 10 bit binary, while other models support 4-bit or 16 bit binary

The numerical output adopts open collector electrode output, with a withstand voltage of 30V and a current of 50mA

The gating signal is the output of the open collector electrode, used to notify external devices to latch the current valid data

The gating period is 64ms, and the logic is an effective low level

Isolation voltage between external and internal circuits 1500V AC, insulation resistance 50M Ω

An external 24V DC ± 2V power supply is required, with a current consumption of 0.2A

The panel indicator lights include BUS indicator light and FILD indicator light

The recommended distance for external wiring should not exceed 30 meters

When wiring, it is necessary to separate it from the power line to reduce electromagnetic interference

Suitable for scenarios that require parallel output of PLC numerical data to external instruments or actuators

This model is currently discontinued, but there are still spare parts available for stock system maintenance

The YASKAWA JAMSC-B1070 register output module, with its multi-channel numerical output capability, flexible BCD/binary configuration, and reliable electrical isolation characteristics, is suitable for Memocon SC series PLC system upgrades, spare parts replacement, and automation control scenarios that require parallel numerical output

JAMSC-B1070寄存器输出模块 产品展示
