CP-317/217IF伺服驱动通信模块  PDF资料

1.产 品 资 料 介 绍：

YASKAWA CP-317/217IF 伺服驱动通信模块

产品概述

CP-317/217IF是安川专为运动控制系统设计的高速通信接口模块，主要与MP2000、MP900系列运动控制器配合使用，通过MECHATROLINK总线实现控制器与伺服驱动器之间的高速、高精度数据交换。

核心特点

1. MECHATROLINK协议：采用安川专有高速运动控制总线，支持M-II或M-III标准

2. 多轴同步控制：最多控制16个伺服轴，微秒级通信周期

3. 高速通信周期：最小125μs，确保高动态响应精度

4. 光纤接口：采用ST光纤接口，彻底隔绝电磁干扰

5. 传输速率：10 Mbps，全双工通信模式

6. 全数字化交换：传输位置、速度、转矩指令及状态报警信息

7. 通信拓扑：M-III支持线型拓扑，最大32节点，传输距离100米

8. 适用控制器：兼容MP940、MP930、MP2000系列

9. PCI接口：标准半长卡，安装于控制器扩展槽

10. LED状态指示：配备Power、RUN、ERR、COM指示灯

11. 宽温工作：-10℃至55℃

12. 串行通信：部分版本支持RS-232C和RS-422/485

13. Memobus协议：支持与PLC、HMI数据交互

14. 紧凑尺寸：约168×107×20mm，重量轻

15. 国际认证：通过CE、UL、RoHS认证

典型应用

高速贴片机、半导体封装设备、工业机器人关节控制、印刷机械电子凸轮、数控机床伺服系统。

CP-317/217IF伺服驱动通信模块 英文介绍

YASKAWA CP-317/217 IF servo drive communication module

Product Overview

CP-317/217IF is a high-speed communication interface module designed by Yaskawa specifically for motion control systems. It is mainly used in conjunction with MP2000 and MP900 series motion controllers to achieve high-speed and high-precision data exchange between controllers and servo drives through the MECHATROLINK bus.

Core Features

MECHATROLINK protocol: using Yaskawa's proprietary high-speed motion control bus, supporting M-II or M-III standards

Multi axis synchronous control: can control up to 16 servo axes, with microsecond level communication cycles

High speed communication cycle: minimum 125 μ s, ensuring high dynamic response accuracy

Fiber optic interface: using ST fiber optic interface to completely isolate electromagnetic interference

Transmission rate: 10 Mbps, full duplex communication mode

Fully digital exchange: transmitting position, speed, torque commands, and status alarm information

Communication topology: M-III supports linear topology, with a maximum of 32 nodes and a transmission distance of 100 meters

Applicable controllers: compatible with MP940, MP930, MP2000 series

PCI interface: standard half length card, installed in the controller expansion slot

LED status indicator: equipped with Power, RUN, ERR, COM indicator lights

Wide temperature range: -10 ℃ to 55 ℃

Serial communication: Some versions support RS-232C and RS-422/485

Memobus protocol: supports data exchange with PLC and HMI

Compact size: approximately 168 × 107 × 20mm, lightweight

International certification: CE, UL, RoHS certified

Typical Applications

High speed surface mount machine, semiconductor packaging equipment, industrial robot joint control, printing machinery electronic cam, CNC machine tool servo system.

CP-317/217IF伺服驱动通信模块 产品展示
