Sorensen XFR40-70电源模块  PDF资料

1.产 品 资 料 介 绍：

Sorensen XFR40-70 电源模块

产品概述

Sorensen XFR40-70是美国Ametek旗下Sorensen品牌推出的2.8kW可编程直流电源，采用2U机架设计，兼具开关电源的紧凑体积和线性电源的低噪声性能。

核心特点

1. 功率参数：输出功率2800W，电压0-40V，电流0-70A

2. 零电压软开关：消除开关尖峰，噪声接近线性电源水平

3. 宽温无降额：0-50℃范围内可输出全额额定电流

4. 可堆叠设计：无需预留通风间隙，节省机架空间

5. 紧凑尺寸：2U高度，19英寸标准机架宽度

6. 输出纹波：电压纹波15mVrms，电流纹波300mArms

7. 负载调整率：电压11.6mV，电流22mA

8. 输入电源：单相190-264Vac，47-63Hz

9. 模拟编程：支持0-5V或0-10V外部模拟控制

10. 通信接口：标配RS232和GPIB接口

11. 保护功能：过压保护和热关断

12. 前面板操作：本地控制旋钮和指示灯

13. 高可靠性：软开关技术降低应力，提升寿命

14. 5年质保：标准保修服务

15. 应用广泛：ATE测试、老化烧机、电镀、磁铁电源等

典型应用

ATE自动测试系统、半导体老化测试、精密电镀工艺、电磁铁励磁、研发实验室通用测试。

Sorensen XFR40-70电源模块 英文介绍

Sorensen XFR40-70 power module

Product Overview

Sorensen XFR40-70 is a 2.8kW programmable DC power supply launched by Sorensen brand under Ametek in the United States. It adopts a 2U rack design and combines the compact size of a switching power supply with the low-noise performance of a linear power supply.

Core Features

Power parameters: output power 2800W, voltage 0-40V, current 0-70A

Zero voltage soft switching: eliminates switch spikes and noise levels close to linear power supply levels

Wide temperature without derating: can output full rated current within the range of 0-50 ℃

Stackable design: No need to reserve ventilation gaps, saving rack space

Compact size: 2U height, 19 inch standard rack width

Output Ripple: Voltage Ripple 15mVrms, Current Ripple 300mArms

Load adjustment rate: voltage 11.6mV, current 22mA

Input power supply: single-phase 190-264Vac, 47-63Hz

Analog programming: supports external analog control from 0-5V or 0-10V

Communication interface: standard RS232 and GPIB interfaces

Protection function: overvoltage protection and thermal shutdown

Front panel operation: Local control knob and indicator lights

High reliability: Soft switching technology reduces stress and improves lifespan

5-year warranty: Standard warranty service

Widely used: ATE testing, aging burning machine, electroplating, magnet power supply, etc

Typical Applications

ATE automatic testing system, semiconductor aging testing, precision electroplating process, electromagnetic excitation, and general testing in R&D laboratories.

Sorensen XFR40-70电源模块 产品展示
