Toshiba DO334控制器模块 PDF资料
1.产 品 资 料 介 绍：
Toshiba DO334 是东芝 PROSEC T3 系列和 V 系列 PLC 系统中的数字量输出模块，用于驱动继电器、电磁阀、指示灯等 24V DC 负载设备。
32路高密度输出，单模块可驱动32个现场设备
晶体管输出类型，采用漏型（Sink）方式，适合连接24V DC负载
额定负载电压24V DC，工作电压范围20.4V至28.8V DC
每通道最大负载电流0.1A，整模块总负载电流3.2A
响应速度快，OFF→ON小于0.5ms，ON→OFF小于1.0ms
采用光耦合器隔离，有效抑制工业现场电噪声干扰
专为高频开关应用设计，适用于高速包装、物料处理等场景
单个插槽宽度提供32点输出，节省PLC机架空间
与东芝PROSEC T3系列和V系列控制器兼容配套
模块化插拔设计，安装维护方便，无需复杂接线
支持DIN导轨安装，适合标准工业控制柜布局
工作温度范围0~55°C，满足一般工业现场环境要求
综上所述，Toshiba DO334 凭借32路高密度输出、快速响应能力及光耦隔离抗干扰特性，为东芝PLC系统提供了高效可靠的数字量输出解决方案。
Toshiba DO334控制器模块 英文介绍
Toshiba DO334 is a digital output module in Toshiba PROSEC T3 series and V series PLC systems, used to drive 24V DC load devices such as relays, solenoid valves, indicator lights, etc.
32 high-density outputs, a single module can drive 32 field devices
Transistor output type, using Sink mode, suitable for connecting 24V DC loads
Rated load voltage 24V DC, operating voltage range 20.4V to 28.8V DC
The maximum load current per channel is 0.1A, and the total load current of the entire module is 3.2A
Fast response speed, OFF → ON less than 0.5ms, ON → OFF less than 1.0ms
Using optocoupler isolation to effectively suppress electrical noise interference in industrial sites
Specially designed for high-frequency switch applications, suitable for high-speed packaging, material handling and other scenarios
Single slot width provides 32 output points, saving PLC rack space
Compatible with Toshiba PROSEC T3 and V series controllers
Modular plug-in design, easy installation and maintenance, no need for complex wiring
Supports DIN rail installation, suitable for standard industrial control cabinet layout
The working temperature range is 0-55 ° C, which meets the requirements of general industrial site environments
In summary, Toshiba DO334 provides an efficient and reliable digital output solution for Toshiba PLC systems with 32 high-density outputs, fast response capability, and optocoupler isolation anti-interference characteristics.
Toshiba DO334控制器模块 产品展示
