Toshiba DI335H控制器 PDF资料
1.产 品 资 料 介 绍：
Toshiba DI335H 是东芝 FA-M3/V3000/TOSMAP 系列 PLC/DCS 系统中的数字量输入模块，用于采集现场设备的开关信号。
32通道高密度设计，单模块可采集32路数字信号
额定输入电压24V DC，工作范围18-30V DC
支持有源信号（PNP传感器）和无源干接点两种输入类型
采用光电耦合隔离，隔离电压≥500V AC，抗干扰能力强
响应时间可选（≤1ms或≤5ms），适应高速信号采集需求
每通道配绿色LED状态指示灯，便于现场故障排查
支持DIP开关切换滤波时间，可在1-20ms范围内调节
8通道共用一个公共端（COM），接线灵活方便
工作温度0-55°C，适用于工业控制柜内安装
与FA-M3、V3000、PROSEC T3/T3H、TOSMAP等东芝控制系统兼容
模块化插拔式设计，安装维护无需螺丝固定
高可靠性，核电及电力行业长期服役验证，MTBF超过10万小时
综上所述，Toshiba DI335H 凭借32通道高密度、光电隔离抗干扰、灵活的输入类型及快速响应能力，成为东芝控制系统中最成熟可靠的数字量输入模块之一。
Toshiba DI335H控制器 英文介绍
Toshiba DI335H is a digital input module in the Toshiba FA-M3/V3000/TOSMAP series PLC/DCS system, used to collect switch signals from field devices.
32 channel high-density design, single module can collect 32 digital signals
Rated input voltage 24V DC, operating range 18-30V DC
Supports two input types: active signal (PNP sensor) and passive dry contact
Adopting optoelectronic coupling isolation, isolation voltage ≥ 500V AC, strong anti-interference ability
Response time optional (≤ 1ms or ≤ 5ms), suitable for high-speed signal acquisition requirements
Each channel is equipped with a green LED status indicator light for easy on-site troubleshooting
Support DIP switch switching filtering time, adjustable within 1-20ms range
8 channels share a common terminal (COM), with flexible and convenient wiring
Working temperature 0-55 ° C, suitable for installation inside industrial control cabinets
Compatible with Toshiba control systems such as FA-M3, V3000, PROSEC T3/T3H, TOSMAP, etc
Modular plug-in design, installation and maintenance do not require screw fixation
High reliability, long-term service verification in the nuclear and power industries, MTBF exceeding 100000 hours
In summary, Toshiba DI335H has become one of the most mature and reliable digital input modules in Toshiba control systems due to its 32 channel high-density, optoelectronic isolation and anti-interference, flexible input types, and fast response capabilities.
Toshiba DI335H控制器 产品展示
