TECHNO KR-505M驱动器 PDF资料
1.产 品 资 料 介 绍：
TECHNO KR-505M 是一款高精度步进电机驱动器/控制器，适用于半导体设备、精密定位系统、自动化产线等场景。
支持256细分微步驱动，理论步距角最小可达0.007°
支持1~256细分动态切换，可在运动中实时调整细分等级
支持双轴或单轴独立控制模式切换
支持S曲线与梯形曲线加减速，速度变化平滑
支持24~80V DC宽电压输入，输出电流0.5~5.0A/相可编程调节
最大脉冲频率500kHz，脉冲响应≤5μs
标配RS-485（Modbus RTU）和USB 2.0通讯接口
16路输入/16路输出，支持脉冲+方向、CW/CCW等信号模式
待机时自动降低相电流，减少发热
内置过流、过压、过热保护功能
DIN导轨或壁挂安装，体积约140×100×45mm
工作温度0~50℃，存储温度-20~70℃
配合高细分驱动，可实现±0.001mm级定位精度
综上所述，TECHNO KR-505M 兼具高精度微步驱动、灵活加减速控制及丰富接口，是精密运动控制场景的实用选择。
TECHNO KR-505M驱动器 英文介绍
The TECHNO KR-505M is a high-precision stepper motor driver/controller suitable for semiconductor equipment, precision positioning systems, automated production lines, and other scenarios.
Support 256 subdivision micro step drive, with a theoretical minimum step angle of 0.007 °
Supports dynamic switching between 1-256 subdivisions, allowing for real-time adjustment of subdivision levels during exercise
Support switching between dual axis or single axis independent control modes
Support S-curve and trapezoidal curve acceleration and deceleration, with smooth speed changes
Support 24~80V DC wide voltage input, output current 0.5~5.0A/phase programmable adjustment
Maximum pulse frequency 500kHz, pulse response ≤ 5 μ s
Standard RS-485 (Modbus RTU) and USB 2.0 communication interface
16 inputs/16 outputs, supporting signal modes such as pulse+direction, CW/CCW, etc
Automatically reduce phase current during standby to minimize heat generation
Built in overcurrent, overvoltage, and overheat protection functions
DIN rail or wall mounted installation, with a volume of approximately 140 × 100 × 45mm
Working temperature 0~50 ℃, storage temperature -20~70 ℃
Combined with high subdivision drive, it can achieve positioning accuracy of ± 0.001mm level
In summary, the TECHNO KR-505M combines high-precision micro step drive, flexible acceleration and deceleration control, and rich interfaces, making it a practical choice for precision motion control scenarios.
TECHNO KR-505M驱动器 产品展示
