IEI SBC-865E2L工业主板 PDF资料
IEI SBC-865E2L 工业主板
产品特点（5条）
采用 Socket 478 架构，支持 Intel Pentium 4 / Celeron 处理器。
基于 Intel 865G 芯片组，支持超线程技术与双通道 DDR 内存。
集成 Intel Extreme Graphics 2 显示核心，支持 CRT 与 LVDS 输出。
板载千兆以太网接口，满足工业网络通信需求。
具备看门狗定时器与工业级电源管理功能，适配长期运行场景。
产品应用领域（10条）
工业自动化控制主机。
无源底板工控机系统集成。
数据采集与监控系统前端。
医疗设备嵌入式控制。
电信与网络通信设备。
自助服务终端与查询机。
工厂产线测试工站。
老旧工业设备的板卡级替换。
需要 PCI/ISA 扩展的嵌入式场景。
长期无人值守运行环境。
总结：IEI SBC-865E2L 是一款基于 Intel 865G 芯片组的 Socket 478 工业主板，集成显示与千兆网络，适用于工业控制、数据采集及通信设备等嵌入式场景。
IEI SBC-865E2L Industrial Motherboard
Product features (5 items)
Adopting Socket 478 architecture, supporting Intel Pentium 4/Celeron processors.
Based on the Intel 865G chipset, it supports hyper threading technology and dual channel DDR memory.
Integrated Intel Extreme Graphics 2 display core, supporting CRT and LVDS outputs.
Onboard Gigabit Ethernet interface, meeting the communication needs of industrial networks.
Equipped with watchdog timer and industrial grade power management function, suitable for long-term operation scenarios.
Product application areas (10 items)
Industrial automation control host.
Passive motherboard industrial computer system integration.
Front end of data collection and monitoring system.
Embedded control of medical equipment.
Telecommunications and network communication equipment.
Self service terminals and query machines.
Factory production line testing station.
Board level replacement of old industrial equipment.
Embedded scenarios that require PCI/ISA extensions.
Long term unmanned operating environment.
Summary: IEI SBC-865E2L is a Socket 478 industrial motherboard based on Intel 865G chipset, integrating display and gigabit network, suitable for embedded scenarios such as industrial control, data acquisition, and communication equipment.
