Copley XTL-230-36 交流伺服驱动器 PDF资料
Copley XTL-230-36
产品特点（5条）
属于 Copley Xenus XTL 系列面板式伺服驱动器，供电范围 100–240 VAC，连续电流 12 A，峰值电流 36 A。
支持多种电机类型：无刷交流伺服、有刷直流伺服、直线电机及音圈电机。
通信与控制接口丰富：CANopen、DeviceNet、RS-232，以及模拟 ±10V、PWM、脉冲/方向指令。
标准反馈为增量编码器，可选 -S 版本（模拟 Sin/Cos 编码器）或 -R 版本（旋转变压器）。
配备 12 路数字输入、4 路数字输出，支持位置、速度、转矩及 PVT、电子凸轮、电子齿轮等控制模式。
应用领域（10条）
半导体制造设备中的精密定位轴
工业机器人关节驱动与直角坐标模组
数控机床进给轴与主轴控制
自动化装配线的拾放与定位机构
包装机械的同步与凸轮控制
物料搬运系统的伺服轴驱动
测试与检测设备的精密负载模拟
需要 CANopen 组网的多轴协调系统
老旧 Xenus 系列驱动器的维修替换
OEM 设备中多类型电机的统一驱动平台
总结：Copley XTL-230-36 是 Xenus 系列 12A/36A 面板式伺服驱动器，支持多协议通信与多种电机及反馈类型，适用于半导体、机器人、机床等精密运动控制场景。
Copley XTL-230-36 交流伺服驱动器 英文介绍
Copley XTL-230-36
Product features (5 items)
Belonging to the Copley Xenus XTL series panel servo drive, with a power supply range of 100-240 VAC, continuous current of 12 A, and peak current of 36 A.
Supports multiple types of motors: brushless AC servo, brushed DC servo, linear motor, and voice coil motor.
Rich communication and control interfaces: CANopen, DeviceNet, RS-232, as well as analog ± 10V, PWM, pulse/direction commands.
The standard feedback is an incremental encoder, which can be selected as - S version (simulating Sin/Cos encoder) or - R version (rotary transformer).
Equipped with 12 digital inputs and 4 digital outputs, supporting control modes such as position, speed, torque, PVT, electronic cam, and electronic gear.
Application areas (10 items)
Precision positioning axis in semiconductor manufacturing equipment
Joint drive and Cartesian coordinate module for industrial robots
CNC machine tool feed axis and spindle control
The picking and positioning mechanism of automated assembly line
Synchronization and Cam Control of Packaging Machinery
Servo axis drive for material handling system
Precision load simulation of testing and inspection equipment
Multi axis coordination system requiring CANopen networking
Repair and replacement of old Xenus series drives
Unified drive platform for multiple types of motors in OEM equipment
Summary: Copley XTL-230-36 is a Xenus series 12A/36A panel servo drive that supports multi protocol communication and various motor and feedback types, suitable for precision motion control scenarios such as semiconductors, robots, and machine tools.
Copley XTL-230-36 交流伺服驱动器 产品图片
