Matrox Y7190-02 63039621298图像采集处理板 PDF资料
Matrox Y7190-02
产品特点（5条）
属于 Matrox Solios 系列模拟图像采集卡，板卡型号标识为 Y7190-02 REV.A。
该系列包括 SOL6M4A 等变体，采用 PCI/PCI-X 或 PCIe 接口，具体总线类型需以实物金手指为准。
支持最多 4 路独立模拟视频输入，10 位 A/D 转换，采样率最高 65 MHz。
板载 64 MB 采集缓冲内存，支持面阵与线阵相机输入。
可选配基于 FPGA 的图像处理核心，用于加速或卸载主机 CPU 的图像处理任务。
应用领域（10条）
半导体元件外观检测与分选
电子组装线上的视觉定位与对位
工业生产线多相机同步图像采集
包装印刷品表面质量检测
汽车零部件尺寸测量与缺陷识别
医疗影像设备的前端图像采集
科研高速摄像数据的实时捕获
老旧 Matrox 视觉系统的板卡维修替换
机器视觉教学与算法开发平台搭建
定制化视觉检测设备集成
总结：Matrox Y7190-02 是 Solios 系列模拟图像采集卡，支持多路输入与高采样率，适用于工业视觉检测与旧系统维修替换。
Matrox Y7190-02 63039621298图像采集处理板 英文介绍
Matrox Y7190-02
Product features (5 items)
Belonging to the Matrox Solios series of analog image acquisition cards, the card model is identified as Y7190-02 REV. A.
This series includes variants such as SOL6M4A, which use PCI/PCI-X or PCIe interfaces. The specific bus type should be based on the physical gold finger.
Supports up to 4 independent analog video inputs, 10 bit A/D conversion, and a maximum sampling rate of 65 MHz.
Onboard 64 MB capture buffer memory, supporting input for both planar and linear cameras.
Optional FPGA based image processing core for accelerating or offloading image processing tasks on the host CPU.
Application areas (10 items)
Appearance inspection and sorting of semiconductor components
Visual positioning and alignment on electronic assembly lines
Multi camera synchronous image acquisition for industrial production lines
Surface quality inspection of packaging printed materials
Measurement of Automotive Component Dimensions and Defect Identification
Front end image acquisition of medical imaging equipment
Real time capture of high-speed camera data for scientific research
Repair and replacement of old Matrox vision system boards
Building a Machine Vision Teaching and Algorithm Development Platform
Customized visual inspection equipment integration
Summary: Matrox Y7190-02 is a Solios series analog image acquisition card that supports multiple inputs and high sampling rates, suitable for industrial vision inspection and old system maintenance and replacement.
