IEI IMBA-XQ354-R11工业主板 PDF资料
IEI IMBA-XQ354-R11
产品特点（5条）
采用 ATX 板型，搭载 Intel Q35 + ICH9DO 芯片组，支持 LGA775 接口的 Core 2 Quad/Duo 及 Celeron 处理器。
配备 4 条 DDR2 DIMM 插槽，支持 800/667MHz 双通道内存，最大容量 8GB。
扩展能力强：提供 1 个 PCIe x16、3 个 PCIe x4（经 PLX 芯片扩展）及 3 个 PCI 插槽。
I/O 接口丰富：包含 12 个 USB 2.0、6 个 RS-232 串口、6 个 SATA II 及 8-bit 数字 I/O。
支持 Intel 主动管理技术（iAMT 3.0）与 TPM 1.2 安全芯片，便于远程管理与系统防护。
应用领域（10条）
工业自动化控制系统
监视与安防系统
高速数据采集设备
高阶测量仪器
多媒体控制终端
游戏与娱乐设备控制
网络通信与数据传输平台
POS 销售点系统
医疗设备控制主机
老旧工控设备维修替换
总结：IEI IMBA-XQ354-R11 是一款基于 Intel Q35 平台的 ATX 工业主板，接口丰富、扩展灵活，适用于自动化控制、数据采集及监控类工业场景
IEI IMBA-XQ354-R11
Product features (5 items)
Adopting ATX board type, equipped with Intel Q35+ICH9DO chipset, supporting LGA775 interface Core 2 Quad/Duo and Celeron processors.
Equipped with 4 DDR2 DIMM slots, supporting 800/667MHz dual channel memory, with a maximum capacity of 8GB.
Strong scalability: Provides 1 PCIe x16, 3 PCIe x4 (expanded with PLX chips), and 3 PCI slots.
Rich I/O interfaces: including 12 USB 2.0 ports, 6 RS-232 serial ports, 6 SATA II ports, and 8-bit digital I/O.
Supports Intel Active Management Technology (iAMT 3.0) and TPM 1.2 security chip for remote management and system protection.
Application areas (10 items)
Industrial automation control system
Surveillance and Security System
High speed data acquisition equipment
Advanced measuring instruments
Multimedia control terminal
Game and Entertainment Device Control
Network Communication and Data Transmission Platform
POS point of sale system
Medical equipment control host
Repair and replacement of old industrial control equipment
Summary: IEI IMBA-XQ354-R11 is an ATX industrial motherboard based on Intel Q35 platform, with rich interfaces and flexible expansion, suitable for industrial scenarios such as automation control, data acquisition, and monitoring
