SICK S30B-2011CA安全激光扫描仪 PDF资料
SICK S30B-2011CA 安全激光扫描仪
产品特点
S30B-2011CA 属于 SICK S300 Advanced 系列安全激光扫描仪，防护区域范围 2 m，警告区域范围 8 m，测距范围可达 30 m。
扫描角度 270°，角度分辨率 0.5°，分辨率可配置为 30 mm、40 mm、50 mm 或 70 mm，响应时间 80 ms。
安全等级为 Type 3（IEC 61496）、SIL 2（IEC 61508）、PL d（EN ISO 13849），具备重启联锁、外部设备监控及多重采样功能。
支持 4 个区域组、12 个可保存区域及 4 种监控情况，通过 PC 配合配置诊断软件进行设定，配置接口为 RS-232。
防护等级 IP65，工作温度 -10°C 至 +50°C，供电 24 V DC，外壳为压铸铝材质。
应用领域
生产线危险区域防护
无人驾驶车辆（AGV）区域保护
小型自动导引车（AGC）安全防护
出入口通道访问控制
机器与设备上的访问控制
安装现场危险点保护
安全机器人平台防护
码垛任务安全物料锁
装卸站点危险区域保护与防绕行
移动与固定式安全应用场景
总结： S30B-2011CA 是 SICK S300 Advanced 系列中防护区域 2 m 的安全激光扫描仪，具备 270° 扫描角度、Type 3/SIL 2/PL d 安全等级及灵活的配置能力，主要面向 AGV、产线危险区域防护及出入口控制等工业安全场景。
SICK S30B-2011CA Safety Laser Scanner
Product Features
S30B-2011CA belongs to the SICK S300 Advanced series of safety laser scanners, with a protection area range of 2 meters, a warning area range of 8 meters, and a ranging range of up to 30 meters.
Scanning angle 270 °, angle resolution 0.5 °, resolution can be configured as 30 mm, 40 mm, 50 mm or 70 mm, response time 80 ms.
The safety level is Type 3 (IEC 61496), SIL 2 (IEC 61508), PL d (EN ISO 13849), with restart interlock, external device monitoring, and multiple sampling functions.
Supports 4 regional groups, 12 storable areas, and 4 monitoring scenarios. It can be set up through a PC in conjunction with diagnostic software, and the configuration interface is RS-232.
Protection level IP65, working temperature -10 ° C to+50 ° C, power supply 24 V DC, shell made of die cast aluminum material.
Application Areas
Protection of hazardous areas in production lines
Automated Guided Vehicle (AGV) Area Protection
Small Automatic Guided Vehicle (AGC) Safety Protection
Access control for entrance and exit channels
Access control on machines and devices
Installation site hazardous point protection
Security robot platform protection
Stacking task safety material lock
Protection of hazardous areas and prevention of detours at loading and unloading stations
Mobile and fixed security application scenarios
Summary: S30B-2011CA is a safety laser scanner with a protection area of 2 meters in the SICK S300 Advanced series. It has a scanning angle of 270 °, a Type 3/SIL 2/PL safety level, and flexible configuration capabilities. It is mainly aimed at industrial safety scenarios such as AGV, production line hazardous area protection, and entrance and exit control.
