OMRON ZS-HLDC11位移传感器 PDF资料
OMRON ZS-HLDC11 位移传感器控制器
产品特点
ZS-HLDC11 是欧姆龙 ZS-HL 系列 2D CMOS 激光型传感器控制器，需配合 ZS-HL 系列传感器头使用，每台控制器连接一个传感器头。
配备 USB 2.0 与 RS-232C 接口，支持最高 115,200 bps 通讯速率，便于与上位系统连接。
线性输出可选电压（-10～10V）或电流（4～20mA）两种方式，通过底部滑动开关切换。
具备判断输出（HIGH/PASS/LOW 三路 NPN 或 PNP 开路集电极），支持多任务模式（最多 4 项任务）。
采用 24VDC 供电，防护等级 IP20，外壳为聚碳酸酯材质，重量约 280g。
应用领域
半导体晶圆厚度与翘曲测量
液晶/ PDP 玻璃板起伏检测
电子元件封装树脂高度测量
密封胶涂布量检测
触摸面板薄膜厚度与间隙同步测量
XY 平台定位与重复精度确认
汽车车身及门板装配偏移测量
电路板共面性检测
陶瓷层压件定位形状测量
喷嘴间隙高精度测量
总结： ZS-HLDC11 是欧姆龙 ZS-HL 系列中的传感器控制器，配合专用激光传感器头实现高精度位移与厚度测量，具备多种输出接口与灵活的任务功能，主要面向半导体、电子元件、液晶显示及汽车制造等领域的精密量测场景。
OMRON ZS-HLDC11 displacement sensor controller
Product Features
ZS-HLDC11 is an Omron ZS-HL series 2D CMOS laser sensor controller that needs to be used in conjunction with ZS-HL series sensor heads. Each controller is connected to one sensor head.
Equipped with USB 2.0 and RS-232C interfaces, supporting a maximum communication speed of 115200 bps, making it easy to connect with the upper system.
There are two options for linear output: voltage (-10~10V) or current (4~20mA), which can be switched through the bottom sliding switch.
Capable of judging output (HIGH-PASS/LOW three-way NPN or PNP open collector), supporting multitasking mode (up to 4 tasks).
Powered by 24VDC, with a protection level of IP20, the casing is made of polycarbonate material and weighs approximately 280g.
Application Areas
Measurement of semiconductor wafer thickness and warpage
LCD/PDP glass panel fluctuation detection
Measurement of resin height for electronic component packaging
Testing of sealant application amount
Simultaneous measurement of thickness and gap of touch panel film
XY platform positioning and repeatability accuracy confirmation
Measurement of offset in car body and door panel assembly
Circuit board coplanarity detection
Measurement of positioning shape of ceramic laminates
High precision measurement of nozzle gap
Summary: ZS-HLDC11 is a sensor controller in the Omron ZS-HL series, which is used in conjunction with a dedicated laser sensor head to achieve high-precision displacement and thickness measurement. It has multiple output interfaces and flexible task functions, mainly targeting precision measurement scenarios in the fields of semiconductors, electronic components, LCD displays, and automotive manufacturing.
