DALSA OR-X4C0-XPD00采集卡 PDF资料
DALSA OR-X4C0-XPD00 采集卡
产品特点
对应 Teledyne DALSA 的 Xcelera-CL PX4 Dual 型号，PCIe Gen1 x4 主机接口。
支持 2 台 Camera Link Base 相机同时采集，或 1 台 Camera Link Medium 相机。
像素时钟 20 至 85 MHz，板载 128MB 帧缓存。
数据接口为 2xMDR CameraLink，带 40-pin 控制排针和多板同步接口。
支持 PoCL 供电，省去相机外接电源线。
板载 FPGA 处理引擎，支持 Bayer 解码和实时阴影校正。
相机 Tap 配置灵活：1/2/3 Tap 单声道 8-16 bit，3 Tap RGB 8/10/12 bit，4 Tap 单声道。
GPIO 为 4 路光耦输入/4 路光耦输出，支持外部触发和正交编码器。
配套 Sapera LT SDK 和 Sapera Vision Software，支持 Windows 7/8/10 和 Linux 64 位。
半长 PCIe 板卡形态，市面流通以拆机件和库存备件为主。
应用领域
工业机器视觉检测系统
双相机同步采集工位
线阵/面阵相机高速图像采集
印刷品表面质量检测
老旧 DALSA 视觉系统采集卡替换
总结
DALSA OR-X4C0-XPD00 就是 Xcelera-CL PX4 Dual 这款 Camera Link 采集卡，双 Base 相机输入、128MB 帧存、PoCL 供电，主要用在工业视觉检测里做图像采集和预处理。
DALSA OR-X4C0-XPD00 acquisition card
Product Features
Corresponding to the Xcelera CL PX4 Dual model of Teledyne DALSA, with PCIe Gen1 x4 host interface.
Supports simultaneous capture by 2 Camera Link Base cameras or 1 Camera Link Medium camera.
Pixel clock 20 to 85 MHz, onboard 128MB frame buffer.
The data interface is 2xMDR CameraLink, with a 40 pin control pin and multi board synchronization interface.
Supports PoCL power supply, eliminating the need for an external power cord for the camera.
Onboard FPGA processing engine, supporting Bayer decoding and real-time shadow correction.
Flexible camera Tap configuration: 1/2/3 Tap mono 8-16 bit, 3 Tap RGB 8/10/12 bit, 4 Tap mono.
GPIO is a 4-channel optocoupler input/4-channel optocoupler output, supporting external triggering and orthogonal encoders.
Comes with Sapera LT SDK and Sapera Vision Software, supporting Windows 7/8/10 and Linux 64 bit.
The semi long PCIe card form is mainly circulated in the market as disassembled parts and inventory spare parts.
Application Areas
Industrial machine vision inspection system
Dual camera synchronous acquisition station
High speed image acquisition using linear/planar cameras
Surface quality inspection of printed materials
Replacement of old DALSA visual system acquisition card
Summary
DALSA OR-X4C0-XPD00 is the Xcelera-CL PX4 Dual Camera Link acquisition card, with dual Base camera input, 128MB frame memory, and PoCL power supply. It is mainly used for image acquisition and preprocessing in industrial vision inspection.
