Bruker Spectrospin BSMS/2 SCB13R-16BIT 控制板模块 PDF资料
Bruker Spectrospin BSMS/2 SCB13R-16BIT 控制板模块
产品特点
属于 BSMS/2 系统里的匀场电流板（SCB），专门管室温匀场线圈的电流输出。
“13R”表示装在机箱右侧槽位，负责第 1 到 13 号电流源。
“16BIT”指板上 HRDAC 的分辨率为 16 位，用于精确控制匀场电流。
板载本地微处理器，通过 VME 总线作为从机运行，软件可下载更新。
模块化插板设计，直接插 BSMS/2 前机箱槽位，换板不用动整机线束。
应用领域
Bruker Avance 系列 NMR 谱仪的室温匀场控制
BSMS/2 机箱的匀场电流源扩展
BOSS1/BOSS2 匀场系统的 Z/X/Y 高阶匀场输出
NMR 磁体场均匀性调节与优化
老旧 BSMS 系统匀场板替换维修
二手 Bruker NMR 控制台整机翻新配套
实验室 NMR 设备板卡级故障排查
匀场电流校准与调试工位
Bruker 谱仪维修站备件库存
科研单位 NMR 系统维护替换
总结
Bruker Spectrospin BSMS/2 SCB13R-16BIT 就是 BSMS/2 机箱里右侧那块管 13 路匀场电流的板子，16 位分辨率，插槽位置和电流源编号都是固定的。
Bruker Spectrospin BSMS/2 SCB13R-16BIT 控制板模块 英文介绍
Bruker Spectrospin BSMS/2 SCB13R-16BIT Control Board Module
Product Features
Belonging to the BSMS/2 system, the shim current board (SCB) is specifically designed to handle the current output of the room temperature shim coil.
13R "indicates that it is installed in the slot on the right side of the chassis and is responsible for the 1st to 13th current sources.
16BIT "refers to the resolution of the HRDAC on the board being 16 bits, used for precise control of the field current.
The onboard local microprocessor runs as a slave through the VME bus, and the software can be downloaded and updated.
Modular plug-in board design, directly plug into the BSMS/2 front chassis slot, and replace the board without touching the entire machine harness.
Application Areas
Room temperature uniform field control of Bruker Avance series NMR spectrometer
Expansion of Uniform Current Source for BSMS/2 Chassis
Z/X/Y high-order shimming output of BOSS1/BOSS2 shimming system
Adjustment and optimization of NMR magnetic field uniformity
Replacement and maintenance of the old BSMS system shimming board
Used Bruker NMR Console Refurbishment Package
Troubleshooting of Laboratory NMR Equipment Board Level Malfunctions
Uniformity current calibration and debugging station
Bruker spectrometer maintenance station spare parts inventory
Maintenance and replacement of NMR system in scientific research institutions
Summary
The Bruker Spectrospin BSMS/2 SCB13R-16BIT is the board on the right side of the BSMS/2 chassis that contains 13 channels of uniform field current. It has a 16 bit resolution, fixed slot positions, and current source numbers.
