ZEISS 000000-1338-815V5控制板卡 PDF资料
ZEISS 000000-1338-815V5 控制板卡
产品特点（5条）
Zeiss LSM 510 META系统用的AOTF驱动板，备件料号000000-1338-815系列。
用于驱动声光可调谐滤光器，控制激光谱线的强度与开关。
板卡附带LVDS线缆，用于与系统其他模块通信。
目前流通件多为从退役LSM 510 META系统拆下的二手件。
V5版本的具体硬件差异与兼容性无法从公开信息确认。
应用领域（10条）
Zeiss LSM 510 META激光扫描共聚焦显微镜激光模块。
AOTF激光强度调节与谱线选择控制。
共聚焦显微成像中的激光开关与空白控制。
多激光谱线同步控制。
荧光显微成像的激光激励链路。
LSM 510系统激光模块维修替换。
退役共聚焦显微镜的板卡拆件周转。
激光扫描显微镜电控系统维护。
科研平台老旧Zeiss共聚焦设备备件供应。
AOTF驱动电路故障排查与替换验证。
总结：该板卡是Zeiss LSM 510 META共聚焦显微镜的AOTF驱动板，用于激光强度与谱线控制
ZEISS 000000-1338-815V5控制板卡 英文介绍
ZEISS 000000-1338-815V5 Control Board
Product features (5 items)
AOTF driver board for Zeiss LSM 510 META system, spare part number 000000-1338-815 series.
Used to drive acousto-optic tunable filters, control the intensity and switching of laser spectral lines.
The board comes with an LVDS cable for communication with other modules in the system.
At present, most of the circulating parts are second-hand parts removed from the retired LSM 510 META system.
The specific hardware differences and compatibility of V5 version cannot be confirmed from public information.
Application areas (10 items)
Zeiss LSM 510 META laser scanning confocal microscope laser module.
AOTF laser intensity adjustment and spectral line selection control.
Laser switch and blank control in confocal microscopy imaging.
Multi laser spectral line synchronization control.
Laser excitation link for fluorescence microscopy imaging.
LSM 510 system laser module maintenance and replacement.
Dismantling and turnover of retired confocal microscope boards.
Maintenance of electronic control system for laser scanning microscope.
The old Zeiss research platform focuses on equipment spare parts supply.
Troubleshooting and replacement verification of AOTF driver circuit.
Summary: This board is the AOTF driver board for Zeiss LSM 510 META confocal microscope, used for laser intensity and spectral line control
ZEISS 000000-1338-815V5控制板卡 产品图片
