Siemens C79298-A3220-B102探测器接口板 PDF资料
Siemens C79298-A3220-B102 探测器接口板
产品特点（5条）
板载高压电源，输出250V–2250V可数字调节，能自动识别探测器类型。
内置高速脉冲放大器，增益12位数字控制，带基线恢复和线移校正。
配备两个独立窗口鉴别器和三个32位计数器，支持脉冲堆积检测。
提供探测器前置放大器供电（±12V），并带自检功能。
高压部分有金属屏蔽罩，板卡工作时最高电压可达2250V，操作需断电。
应用领域（10条）
Bruker D8衍射仪探测器信号采集。
闪烁计数器高压供电与脉冲处理。
正比计数器信号放大与计数。
X射线衍射强度测量链路。
Kevex型探测器TTL脉冲计数输入。
衍射仪控制机架内探测器接口单元。
老旧D8系统探测器板卡替换维修。
实验室X射线分析仪器信号调理。
脉冲高度鉴别与能量窗口选择。
高计数率条件下的基线校正处理。
总结：C79298-A3220-B102是Bruker D8衍射仪探测器接口板，集高压供电、脉冲放大成形和计数鉴别于一体，用于X射线探测器信号的完整处理链路。
Siemens C79298-A3220-B102探测器接口板 英文介绍
Siemens C79298-A3220-B102 detector interface board
Product features (5 items)
Onboard high-voltage power supply, output 250V-2250V with digital adjustment, capable of automatically identifying detector types.
Built in high-speed pulse amplifier, gain 12 bit digital control, with baseline recovery and line shift correction.
Equipped with two independent window discriminators and three 32-bit counters, supporting pulse pile up detection.
Provide power supply for the detector preamplifier (± 12V) with self checking function.
The high-voltage part has a metal shielding cover, and the maximum voltage of the board during operation can reach 2250V. Power off is required for operation.
Application areas (10 items)
Bruker D8 diffractometer detector signal acquisition.
High voltage power supply and pulse processing for scintillation counter.
Proportional counter signal amplification and counting.
X-ray diffraction intensity measurement link.
Kevex detector TTL pulse counting input.
The interface unit of the detector inside the diffraction instrument control rack.
Replacement and repair of old D8 system detector boards.
Signal conditioning of laboratory X-ray analysis instruments.
Pulse height discrimination and energy window selection.
Baseline correction processing under high count rate conditions.
Summary: C79298-A3220-B102 is a Bruker D8 diffractometer detector interface board that integrates high-voltage power supply, pulse amplification and shaping, and counting discrimination, used for the complete processing chain of X-ray detector signals.
Siemens C79298-A3220-B102探测器接口板 产品图片
