Siemens C79298-A3220-B105四轴分度器/驱动器模块 PDF资料

1.产 品 资 料 介 绍：

Siemens C79298-A3220-B105 四轴分度器/驱动器模块

产品特点（5条）

1. 单板控制4个步进电机，集成DSP与板载驱动器。

2. 支持S曲线、梯形、速度轮廓及电子齿轮等多种轨迹模式。

3. 每轴带增量编码器反馈，位置/速度/加速度寄存器为32位。

4. 板载驱动支持24V/2A输出，电流设定与微步模式可软件选择。

5. 驱动器与总线及DSP逻辑电气隔离，降低噪声干扰。

应用领域（10条）

1. Bruker D8衍射仪测角仪四轴驱动控制。

2. 衍射仪欧拉环Z轴驱动。

3. 马达驱动狭缝控制。

4. 防散射狭缝定位。

5. X射线衍射系统样品台运动控制。

6. 步进电机多轴联动定位。

7. 编码器反馈闭环控制回路。

8. 老旧Bruker D8系统驱动器板替换。

9. 衍射仪控制机架内电机驱动通道。

10. 实验室分析仪器多轴运动控制单元维修备件。

总结：该模块为四轴步进电机分度/驱动板，用于多轴联动定位与闭环控制，常见于Bruker D8衍射仪等分析仪器的运动控制链路，选型替换时需核对实物丝印与机型配置

Siemens C79298-A3220-B105四轴分度器/驱动器模块  英文介绍

Siemens C79298-A3220-B105 Four Axis Dimensioner/Driver Module

Product features (5 items)

Single board controls 4 stepper motors, integrating DSP and onboard drivers.

Supports multiple trajectory modes such as S-curve, trapezoid, speed profile, and electronic gear.

Each axis is equipped with incremental encoder feedback, and the position/velocity/acceleration registers are 32-bit.

The onboard driver supports 24V/2A output, and the current setting and micro step mode can be selected by software.

The driver is electrically isolated from the bus and DSP logic to reduce noise interference.

Application areas (10 items)

Bruker D8 diffractometer angle measuring instrument with four axis drive control.

Diffraction instrument with O-ring Z-axis drive.

Motor driven slit control.

Anti scattering slit positioning.

Motion control of X-ray diffraction system sample stage.

Multi axis linkage positioning of stepper motor.

Encoder feedback closed-loop control loop.

Old Bruker D8 system driver board replacement.

The diffraction instrument controls the motor drive channel inside the frame.

Maintenance spare parts for multi axis motion control unit of laboratory analytical instruments.

Summary: This module is a four axis stepper motor indexing/driving board used for multi axis linkage positioning and closed-loop control. It is commonly used in the motion control link of analytical instruments such as Bruker D8 diffractometer. When selecting and replacing, it is necessary to check the physical silk screen and model configuration

Siemens C79298-A3220-B105四轴分度器/驱动器模块 产品图片
