Jeol AP002310(00)图像采集卡 PDF资料
Jeol AP002310(00) 图像采集卡
产品特点（5条）
面向JEOL电镜系统，完成探测器图像信号的采集与转换。
板载信号调理电路，支持增益调节与模数转换。
适配JEOL主机背板总线或专用接口，协同主控系统工作。
工业级板卡材质与连接器，适应电镜室长时间连续运行。
以板卡备件形式供货，用于图像采集通道的故障替换。
应用领域（10条）
扫描电镜二次电子图像采集。
扫描电镜背散射电子图像采集。
透射电镜荧光屏图像数字化。
STEM模式明场/暗场信号采集。
EDS元素面分布图图像信号通道。
电子衍射花样数字化记录。
低剂量成像信号累积与读出。
电镜图像帧抓取与实时显示。
老旧JEOL电镜图像采集系统维修替换。
电镜附件相机接口的信号中转。
总结：该板卡是JEOL电镜成像链路中的图像采集环节，负责探测器信号的转换与预处理，保障图像数据可靠送入主控系统
Jeol AP002310 (00) Image Acquisition Card
Product features (5 items)
Complete the acquisition and conversion of detector image signals for JEOL electron microscopy system.
Onboard signal conditioning circuit, supporting gain adjustment and analog-to-digital conversion.
Adapt to JEOL host backplane bus or dedicated interface, and work together with the main control system.
Industrial grade board material and connector, suitable for long-term continuous operation in the electron microscope room.
Supply in the form of spare board components for fault replacement of image acquisition channels.
Application areas (10 items)
Scanning electron microscopy secondary electron image acquisition.
Scanning electron microscopy backscattered electron image acquisition.
Digitization of transmission electron microscopy fluorescence screen images.
STEM mode bright/dark field signal acquisition.
EDS element surface distribution map image signal channel.
Digital recording of electron diffraction patterns.
Accumulation and readout of low-dose imaging signals.
Capture and real-time display of electron microscopy image frames.
Repair and replacement of old JEOL electron microscope image acquisition system.
Signal relay for electron microscope attachment camera interface.
Summary: This board is the image acquisition link in the JEOL electron microscopy imaging chain, responsible for the conversion and preprocessing of detector signals, ensuring the reliable transmission of image data to the main control system
