OSIRIS 616000-022-01采集卡 PDF资料
OSIRIS 616000-022-01 采集卡是 Curtiss-Wright Controls（原 Primagraphics）生产的 Osiris 系列双通道雷达接口板，属于 PCI 规格的雷达信号采集与处理卡。
产品特点（5条）
双通道雷达接口：支持两路独立雷达通道输入，可处理雷达视频、触发信号及方位数据。
板载 FPGA 处理：通过 FPGA 完成高速雷达信号处理，输出双通道视频流。
高速 PCI 接口：采用 64 位/66 MHz PCI 接口，每通道 DMA 传输速率可达 25 MB/s。
灵活采样能力：两路模拟输入采样频率最高 50 MHz，可混入最多 8 路数字雷达输入。
软件支持完善：提供 Windows、Linux/x86 及 Solaris/x86 驱动和板级支持包。
产品应用领域（10条）
雷达视频信号采集与处理
国防与航空航天嵌入式系统
PC 工作站雷达信号接入
COTS VME/CompactPCI 系统集成（PMC 版本）
双通道独立雷达视频处理
雷达信号数字化与 DMA 传输
与 RVP 雷达视频处理器配合组网
雷达接口改造与升级项目
雷达显示客户端数据分发
旧式雷达接口适配
结尾
OSIRIS 616000-022-01 采集卡是 Osiris 系列中 PCI 规格的双通道雷达接口板，核心功能为雷达信号的采集、FPGA 处理与 PCI 总线传输，适用于雷达视频处理及国防嵌入式系统集成场景。
OSIRIS 616000-022-01采集卡 英文介绍
The OSIRIS 616000-022-01 acquisition card is an Osiris series dual channel radar interface board produced by Curtiss Wright Controls (formerly Primagraphics), and belongs to the PCI specification radar signal acquisition and processing card.
Product features (5 items)
Dual channel radar interface: supports two independent radar channel inputs, capable of processing radar video, trigger signals, and azimuth data.
On board FPGA processing: High speed radar signal processing is completed through FPGA, and dual channel video streams are output.
High speed PCI interface: adopting 64 bit/66 MHz PCI interface, with a DMA transfer rate of up to 25 MB/s per channel.
Flexible sampling capability: The maximum sampling frequency for two analog inputs is 50 MHz, and up to 8 digital radar inputs can be mixed in.
Complete software support: Provides Windows, Linux/x86, and Solaris/x86 drivers and board level support packages.
Product application areas (10 items)
Radar video signal acquisition and processing
Defense and Aerospace Embedded Systems
PC workstation radar signal access
COTS VME/CompactPCI System Integration (PMC Version)
Dual channel independent radar video processing
Digitization of Radar Signals and DMA Transmission
Networking with RVP radar video processor
Radar interface renovation and upgrade project
Radar display client data distribution
Old style radar interface adaptation
ending
The OSIRIS 616000-022-01 acquisition card is a dual channel radar interface board with PCI specifications in the Osiris series. Its core functions include radar signal acquisition, FPGA processing, and PCI bus transmission. It is suitable for radar video processing and defense embedded system integration scenarios.
OSIRIS 616000-022-01采集卡 产品图片
