VMIVME-7486 处理器模块
VMIVME-7486 是 VMIC（GE Fanuc / Abaco Systems）推出的一款 VMEbus 架构 PC/AT 兼容处理器模块，主要用于工业控制、军工系统及嵌入式计算平台，属于高可靠性单板计算机CPU模块。
1、基于VMEbus总线架构的单板计算机处理器模块
2、采用Intel 80486系列CPU，主频最高可达66MHz
3、内置缓存结构（约8KB），提升数据处理效率
4、最大支持约16MB DRAM内存扩展
5、兼容PC/AT计算机体系结构，可运行DOS及Windows系统
6、集成VGA图形显示功能，支持最高1024×768分辨率
7、板载IDE硬盘与软驱控制器，支持本地存储设备
8、提供RS-232串口与并行接口，便于外设通信
9、支持键盘接口与实时时钟（带电池保持）
10、具备VMEbus完整主控功能（系统控制器能力）
11、支持内存访问保护模式与实模式运行
12、具备字节交换功能，适配不同数据格式系统
13、采用自定义门阵列技术，实现VME总线完整功能支持
14、可作为VME系统主CPU或嵌入式控制核心使用
15、广泛应用于工业自动化、过程控制及高可靠嵌入式系统
VMIVME-7486 处理器模块在VME系统中属于核心计算单元，能够提供稳定的工业级计算能力，并支持复杂控制与数据处理任务。
VMIVME-7486处理器模块 英文介绍
VMIVME-7486 processor module
VMIVME-7486 is a VMEbus architecture PC/AT compatible processor module launched by VMIC (GE Fanuc/Abaco Systems), mainly used in industrial control, military systems, and embedded computing platforms. It is a high reliability single board computer CPU module.
1. Single board computer processor module based on VMEbus bus architecture
2. Using Intel 80486 series CPU, the maximum clock speed can reach 66MHz
3. Built in cache structure (approximately 8KB) to improve data processing efficiency
4. Maximum support for approximately 16MB DRAM memory expansion
5. Compatible with PC/AT computer architecture, capable of running DOS and Windows systems
6. Integrated VGA graphics display function, supporting up to 1024 × 768 resolution
7. Onboard IDE hard drive and floppy drive controller, supporting local storage devices
8. Provide RS-232 serial and parallel interfaces for easy communication with external devices
9. Supports keyboard interface and real-time clock (with battery backup)
10. Equipped with complete control function of VMEbus (system controller capability)
11. Supports memory access protection mode and real mode operation
12. Capable of byte swapping and adapting to different data format systems
13. Adopting custom gate array technology to achieve complete functional support for VME bus
14. Can be used as the main CPU or embedded control core of VME system
15. Widely used in industrial automation, process control, and highly reliable embedded systems
The VMIVME-7486 processor module is a core computing unit in the VME system, capable of providing stable industrial grade computing power and supporting complex control and data processing tasks.
VMIVME-7486处理器模块 产品展示
