Miteq ASSEMBLY-D16997机械加工组件 PDF资料
Miteq ASSEMBLY-D16997 是 Narda-MITEQ（原 MITEQ）高压电源组件中的主桥 CCA（Main Bridge CCA）散热器组件，属于微波/射频设备电源子系统的一部分。
产品应用领域（10条）
高压电源组件（HVPS Assembly）散热管理
主桥 CCA（Main Bridge CCA）温度控制
微波功率放大器电源系统
射频通信设备电源模块
军用及航天级射频系统
卫星通信（SATCOM）设备
测试与测量仪器电源单元
雷达系统电源组件
电子战（EW）设备电源子系统
高可靠性工业射频应用
产品参数（3条）
功能定位：主桥 CCA 散热器组件，带温度开关
关联接口：J1 连接器（主桥 CCA 侧）
所属组件：HVPS（高压电源）装配体
结尾
Miteq ASSEMBLY-D16997 在 Narda-MITEQ 高压电源子系统中承担主桥电路的散热管理功能，是保障电源模块稳定运行的关键机械加工与热管理组件。
Miteq ASSEMBLY-D16997机械加工组件 英文介绍
Miteq ASSEMBLY-D16997 is the main bridge CCA heat sink component in the Narda-MITEQ (formerly MITEQ) high-voltage power supply assembly, which is part of the microwave/RF equipment power supply subsystem.
Product application areas (10 items)
High Voltage Power Supply Assembly (HVPS Assembly) Heat Dissipation Management
Main Bridge CCA Temperature Control
Microwave power amplifier power supply system
RF communication equipment power module
Military and aerospace grade RF systems
Satellite Communication (SATCOM) equipment
Power supply unit for testing and measuring instruments
Radar system power components
Electronic Warfare (EW) Equipment Power Subsystem
High reliability industrial RF applications
Product parameters (3 items)
Functional positioning: Main bridge CCA radiator component with temperature switch
Associated interface: J1 connector (main bridge CCA side)
Component: HVPS (High Voltage Power Supply) Assembly
ending
Miteq ASSEMBLY-D16997 is responsible for the heat dissipation management function of the main bridge circuit in the Narda MITEQ high-voltage power supply subsystem, and is a key mechanical processing and thermal management component to ensure the stable operation of the power module.
Miteq ASSEMBLY-D16997机械加工组件 产品图片
